0-100A 0-60V DC RC Airplane Battery Power Meter Analyzer Helicopter Watt Balancer

0-100A 0-60V DC RC Airplane Battery Power Meter Analyzer Helicopter Watt Balancer

Product details:

- Measures energy (AH), Power(W), Current( A) and Voltage(V).

- Connector to use an optional receiver battery for measurement down to 0V.

- Accurate and precise:  0.01A current and 0.01V voltage resolutions.

- Rugged-handles 50A continuous and 100A peak at 60V.14 ga.

- Super fine stranded, high temperature, silicone rubber insulated wire.

- Small and light with a tough plastic case available in several colors.

- Acts like a wire, so doesn't affect model's performance.

- Precision Alu-Chrom current sensing resistor, with only 0.001 0hms resistance and circuitry that draws only 7mA.

- Uses DSP to increase ADC resolution and differential measurement amplifiers to increase noise immunity.

- Powerful: built-in 8MIPS micro-controller.

Specifications:

- Item Name: RC Airplane Battery Power Meter

- Color: Blue

- Power: 0-6554W 0.1W

- Charge: 0-65AH, 0.001AH Resolution, 0-6554AH for Doc wattson, 0.1Ah resolution

- Energy: 0-6554Wh, 0.1Wh Resolution, 0-655Kwh for Doc wattson, 0.01Kwh resolution

- Measurement Update period: 400ms, 650ms for Doc

- Signal Sampling Rate: Samples/S

- Data Queues: 2s

- In Circuit Resistance: 0.001Ohms

- Operation Current: 7mA

- Auxiliary Power Voltage: 4.0V-60V, e.g for Rec. Bat

- Weight: 0.3kg

- Display Screen: 1602 STN LCD, 70 x 26 mm

- Normal Operate Conditions: 0-50℃ ambient temperature. Non-humidity, Max Temp reduced at 100A

- Size: 85.5 x 49.6 x 20.3 mm

- Weight: 0.3kg

Package Included:

- 1 x Power Meter

- 1 x English User Manual
