Tags: Load Cell Amplifier
Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $32.85 | $32.18 | $31.17 | $29.83 | Contact US |
Description:
- Suitable for all kinds of load sensor signal is converted to 0-5V,0-10V or 4-20mA
- You can pick up 1-4 sensors,can output 0-5V/0-10V or 4-20mA
- The bridge road input impedance:2KΩ
- Input sensitivity:1.5~2.1 MV/V
- Sensor excitation voltage:5V DC
- Load capacity:87 Ω (four 350 ohm sensor parallel)
- The working power supply:18~26V DC
- Precision:0.3%FS
- Temperature characteristics:Better than 100 PPM
- Working temperature:0~50C
- Weight:90G
- Size and shape:115x80x34 (the center of the mounting hole distance:97)mm
Package Contents:
- 1 x 0-5V/10V 4-20mA Load Cell sensor Amplifier
