| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $21.68 | $21.24 | $20.57 | $19.69 | Contact US |
- Fully Complies with IEEE802.3 10Base-T,IEEE802.3u 100Base-TX/IEEE802.3u 100Base-FX,IEEE802.3z 1000Base-FX Standard.
- Auto-detection of half/full duplex transfer mode for Tx port
- Auto-negotiation of 10/100/1000Mbps rate and Auto-MDI/MDIX for Tx port
- Extend fiber distance up to 20km for single-mode fiber
- 6 LED display for Power, FDX/Col, FX (Link/Act), TX (Link/Act), FX 1000, TX 100
- Easy-to-view LED indicators provides status to easily monitor network activity
Specifications:
| Standard | IEEE802.3 10BASE-T Ethernet |
||
| RJ-45 Port | Auto-MDI/MDIX | ||
| Fiber Port | Fiber Type | Wavelength | Send-Power |
| SC | 1310/1550nm | 20dBm(min.) 0dBm(max.) | |
| Frequency Offset | ±125,000bps (or ± 100ppm) | ||
| MTU | More than 9036 bytes | ||
| Dimensions(WxDxH) | 94x71x27mm (External power) | ||
| Input Voltage | DC5V2A( External power input : AC100V-AC240V/50-60HZ ) | ||
| OperationTemperature | 0°C~70°C | ||
| Store Temperature | -40°C~85°C | ||
| Humidity | 5%~95% non-condensing | ||
| Weight | 0.3kg/Piece (External Power) | ||
