Specification:
- HF Band short wave power amplifier
- Input power:5W (FM AM);10WPEP(SSB CW)
- Output power:the high level >=100W(7MHz & 14MHz & 21MHz power:>120W);The low level is around 50W.
- Frequency range:1.5-30MHz
- Working voltage:13.8V
- Full load current:18A
- Working mode:AB type
- Receive transmit LED indicator,temperature prompt LED indicator
- Auto bias voltage control,auto transceiver conversion circuit.
- Inner reserved enough LPF install position,convenient for update.
Attention:The amplifier does not have SWR protection circuit.Please use it with power SWR meter.No low-pass filter.
Package List:
- 1 x Power Amplifier
