1230-2402 24V 250A Motor Controller China-Made Motor Speed Controller for Curtis Liftstar Noblelift

Availability: In stock, usually dispatched in 1 business day

  • Price:$147.69
  • Price in reward points: 1477 Reward Points: 15
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $144.74 $141.78 $137.35 $131.44 Contact US
Quantity:

1230-2402 24V 250A Motor Controller China-Made Motor Speed Controller for Curtis Liftstar Noblelift

Description:

1230 programmable speed controllers provide smooth and seamless control of AC induction motors. An advanced MOSFET power section, combined with a sophisticated micro-processor provides high efficiency and silent operation.

Application:

The 1230 AC controller is designed for small material handling and other light industrial vehicles using AC induction motors, such as pallet movers, stackers, personnel carriers and sweeper/scrubbers.

Features:
State-of-the-art Design
• Responsive and accurate closed-loop speed control.
• Smooth regenerative braking and seamless reversing.
• Internal battery discharge indicator (BDI), hour meter and maintenance timer.
• High frequency, silent MOSFET design.
• Compact and rugged housing with fuse mounting.

Highly Flexible and Programmable
• Fully compatible with the original 311 handheld and 1314 PC programming station for testing, diagnostics and parameter adjustments.
• Multi-mode feature allows two selectable vehicle operating profiles.
• Programmable forward and reverse speeds, acceleration and deceleration/braking rates.
• Serial interface for the Model 840 gauge for BDI, hour meter, timer and fault code display
• Multiple throttle types supported; 5kΩ, 0-5V and wig-wag.
• Easily configured to match most AC induction motors.
• Electromagnetic brake driver (2 amps).

Safe and Protected
• Meets or exceeds EEC fault detection and safety requirements.
• Emergency reverse function with signal continuity check.
• "Ramp restraint" feature restricts vehicle movement while in neutral.
• Power-on self test and continuous fault monitoring.
• Dual watchdog circuits ensure proper software operation.
• Programmable High Pedal Disable (HPD) and Static Return to Off (SRO) functions.
• Shorted and open throttle faults are detected with proper controller shutdown.
• Internal clamps for inductive fly-back of coils.
• Controller over-temperature protection.
• Over and under-voltage protection.
• Low battery charge LED warns operator of possible battery damage.
• On-board fault code status LED with external LED driver for remote viewing of fault codes.

Package Included:
• 1 x Motor Controller

Note:
• Battery is not included in the package.


Packaging Details:
• G.W.: 1.6kg
