Specification:
- 138M-4.4G signal generator,spectrum analyzer,can connect tracking generator
- Signal generator and spectrum analyzer frequency range: 138MHz-4.4GHz
- MIN step: 1K
- Output power(reference): -2.35dBm@200M,-2.63dBm@500M,-2.69dBm@1G,2.89dBm@2G,-2.66dBmBM@3G,-5.36dBm@4G,-7.65dBm@5G,-10.42dBm@6G
- Frequency accuary(calibration): +-0.1k@1GHz
- Spectrum analyzer max liner input power: +0dBm
- Spectrum analyzer not damage input power: +20dBm
- Noise level: -80DBM@0.5G
- Power: +5V/0.35A,USB2.0,USB3.0
- Interface: USB,SMA
