2.4GHz Radio Telemetry Kit Transmitter Receiver RC Wireless Data Link for Agricultural Drone

2.4GHz Radio Telemetry Kit Transmitter Receiver RC Wireless Data Link for Agricultural Drone

Description:
2.4GHz wireless radio telemetry is used for wireless data transmission between flight control and ground software. It can make your drone controlled when it is beyond visual range. With 2.4GHz frequency band for data transmission, it can be widely used.

Strong Anti-Interference Ability: 2.4GHz radio telemetry adopts advanced frequency-hopping algorithm, which has a fabulous anti-interference ability. It means that thousands of radio telemetries can be operated at the same time.

Long-Distance Communications: In an open environment, 2.4GHz telemetry features data transmission distance up to 3km, which perfectly meets the demand of users for BVR flight.

General Parameters:
- Antenna: 2.0 dBi high gain antenna
- Serial Data Transmission Rate: 115200bps
- Channels: FCC: 79. CE: 43

Transceiver:
- Frequency Band: 2400-2483.5MHz
- Data Throughput: 280 kbps
- Frequency Hopping Technology: FHSS
- Maximum Power: FCC: 21 dBm. CE: 10 dBm
- Supply Voltage: 5 V±50 mV
- Operating Current:
  Certificate Standard: FCC (125 mW); CE (10 mW)
  Instantaneous Current For Transmitting: 156mA; 60mA
  Instantaneous Current For Receiving: 56mA; 56mA
  Non-Working Current: 12.5mA; 12.5mA
- Receiving Sensitivity (1% PER): 500 kbps, -88dbm; 280 kbps, -92dbm
- Effective Range (Outdoor Open Space): FCC: 3km (2.5 miles); CE: 1.0km (0.6 miles)

Other Parameters:
- Required Environment: -40℃ to 85℃
- Storage Temperature: -50℃ to 150℃
- Sizes:
  Air Station: 36.7 x 50 x 11.8mm
  Ground Station: 38 x 55.6 x 11.8mm

Package Included:
- 1 x Receiver
- 1 x Transmitter
- 1 x Receiver Antenna
- 1 x Transmitter Antenna
