200W HTPC Digital Player NAS with High Current Linear Power Supply 12V/16V/19V/24V 2 Channel Output

200W HTPC Digital Player NAS with High Current Linear Power Supply 12V/16V/19V/24V 2 Channel Output

Description:
The circuit structure is a classic high-precision voltage stabilizing circuit with expansion current, two outputs are connected in parallel, and each group of outputs has an independent overcurrent protection circuit, which increases reliability and safety. Large capacitor filtering is used for input and output, which further improves the quality of DC power supply! Very low internal resistance, high conversion rate, and very low ripple factor, creating this very high-performance power supply.

Specification:
Size: 230 x 70 x 263mm
Weight: 5.7kg

Features:
-Customized 250W pure copper toroidal transformer.
-Ultra-low noise voltage regulator circuit composed of precision reference + high current output tube.
-Aluminum alloy wire drawing process shell, high-end and fashion.
-Built-in precision adjustable resistor to fine-tune the output voltage.
-ALPS power switch.
-Adopt Nikon, Black King Kong electrolysis.
-Suitable for polishing all kinds of HTPC high-definition audio and video playback computers, NAS power upgrades, actual test ripple within 5MV.

Package List:
-1 x Digital Player
-1 x Power Cord
-1 x DC 5.5-2.5 Output Cable

Note:
-The linear power supply with an output voltage of 19V 10A or 12V 14A can be customized, and the rear 2 output ports are output in parallel. The specifications of the DC output plug are 5.5-2.5.
-Voltage can be customized 12V, 16V, 19V, 24V and other parameters, the maximum output power is 200W, the maximum output current is 14A (depending on the output voltage, for example, the maximum current of 24V is 8.3A, the maximum current of 19V is 10.5A, and the maximum current of 12V can reach 14A)
