3018Pro Max 3 Axis Mini Laser Engraver Standard +5500mW Laser +Offline Control 1.8" Screen Unfinished

3018Pro Max 3 Axis Mini Laser Engraver Standard +5500mW Laser +Offline Control 1.8" Screen Unfinished

Specifications:
- Laser: 5500mW
- Software: GRBL, Weidiaoguanjia, etc.
- Chuck Specifications: ER11, 3.175MM (can be equipped with 0-7mm)
- Working Area: 300 x 180 x 40mm (L*W*H)
- Frame Size: 400 x 330 x 240mm (L*W*H)
- Ball Screw: Professional T8 Ball Screw, Lead 4mm, Pitch 2mm
- Motor: 42 Stepper Motor 1.3A 0.25N.m
- 775 Spindle Motor: 24 V, 10000r /min
- Power Supply: 24V 5A Full Power (Output Voltage 110-240V)
- Support System: For Windows XP / Win 7 / Win 8 / Win10
- Body Materials: Aluminum + Bakelite Plates
- Other Body Materials: Bakelite Plates + Injection Molding Parts

Features:
- Upgraded controller board
- GRBL1.1f firmware ensures stable performance
- Support offline engraving, offline tool setting and carving
- Support 2P/3P laser, enabling PWM / TTL signal control, and 0-100% adjustable power
- Its spindle supports PWM 0-100% adjustable power
- Stepper motor with over-current protection to avoid damage. Upgraded DRV8825 drive outperforms A4988
- Easy Operation: Directly import pictures to engrave, programming and extra design are not in need
- Premium materials to build an amazing laser engraving machine

Package Included:
- 1 x Mini Laser Engraving Machine
- 10 x Cutters
- 4 x Set of Plates
- 1 x 4G U Disk
- 1 x ER11
- 1 x 5500mW Laser
- 1 x Offline Control 1.8" Screen

Note:
- Controller board is included in the package.
- The laser engraver kit is unfinished. Self-assembling is needed.
