5.6M/18.4FT GP Telescopic Antenna for Ham Radio Users to DIY Shortwave Antenna Yagi Antenna
Description:
It can be used to DIY shortwave radio and telescopic antenna element. It can also be used to DIY positive V antenna, GP antenna and Yagi antenna.
Parameters:
- Unfolded length: 5.6m/18.4ft
- Number of Sections: 14 Sections
- Weight: 285g/0.6lb
- Folded length: 50cm/19.7" (including nut)
- Connecting nut: M10 (male thread)
- Diameter of the first section: 16mm/0.6"
- Distal diameter: 3.6mm/0.1"
- Material: 201 reinforced stainless steel
Special Process:
The bottom 10 sections are all made with secondary reinforcing ribs, changing the force point and making it stronger and tighter. Of course, it will take a little more effort than ordinary telescopic antenna when folding and stretching. Therefore, it can reduce upright shaking and avoid automatic shrinkage to extend its lift span.
When extending, it is recommended to pull out section by section from the top, and when retracting, retract section by section from the bottom.
Package Included:
- 1 x Telescopic Antenna
