5.8G 2000MW Weirless VideoTransmitter AV 8CH with HD19 Plus Mini HD Aerial Camera Kit for FPV Multicopter

5.8G 2000MW Weirless VideoTransmitter AV 8CH with HD19 Plus Mini HD Aerial Camera Kit for FPV Multicopter

Description:
5.8G 2000mW video transceiver kit has 8 channels. Because of the high frequency, the antenna gain and efficiency are high. The transmission distance is far, the channel has no interferrence from other equipment. Comes with a heat sink and MIC, no need to worry about the heat dissipation problem, can cooperate with 2.4G remote control.

Transmitter main features:
- 5.8GHz video / audio synchronous transmission (compatible with PAL and NTSC)
- Compact structure, small volume, high transmission power (2000mW)
- Integrated micro air cooling radiator, the heat is small, the work efficiency is high.
- Apply large-scale integrated circuits, high reliability
- Working voltage: DC 7.4V-13V
- 8 working channels, DIP switch option settings
- Built-in frequency phase locked loop, low harmonic radiation, high reliability and stability
- Digital phase locked loop circuit, no temperature drift phenomenon
- Working current: 1500mA
- Size: 69mm x 31mm x 26mm
- Weight: 68.5g (including antenna, and no wire)

Opearting frequency:
- CH1:5705 CH2:5685
- CH3:5665 CH4:5645
- CH5:5885 CH6:5905
- CH7:5925 CH8:5945

Parameters of HD19 Plus:
- Image Sensor: 1/2.5" CMOS
- Effective Pixels: 5.0 Mega Pixels
- Lens: fixed focus; f: 2.8mm; angle of view: 170deg
- Exposure Control: Auto
- White balance: Auto
- Photos Format: JPEG
- Pixels: 2592 X 1944
- Single continuous shooting: Take 3/5/10 photos per one shooting
- Auto continuous shooting: Take one photo every 3/5/10/30/60s
- Video Format: mov(H.264 video compression)
- Resolutions: 16:9 1920 X 1080(30fps)/4:3 1440 X 1080(30fps)/16:9 1280 X 720(60fps)/16:9 1280 X 720(30fps)
- Video section: 5/10/15/30min optional
- Quality/Bit rate: High, Medium, Low
- Audio channel: Mon
- Memory: High speed Micro SD card(TF card) up to 32GB (Not included)
- Multifunction USB: Mini USB
- Multifunction interface: DC input; AV output; remote input
- Dimensions: 37mm X 37mm X 31mm
- Net Weight: 60g
- Power adapter: 5V/ 1.5A

Package included:
- 1 x 5.8G 2000MW Weirless Transmission AV 8CH with HD19 Plus Mini HD Camera Kit
