5.8GHz 32CH Dual-Way Wireless FPV 7" LCD Diversity Receiver Monitor 5.8g 32channels
Description:
- This 5.8GHz Diversity LCD Screen offers the perfect solution for any 5.8GHz FPV system. It features its own in-built 2CH 5.8GHz A/V receiver, allowing it to receive directly from your FPV model's A/V transmitter! This means it can eliminate the need for expensive FPV goggles, or can be used simply as a way to display your FPV model's video for others to view as you fly.
- Featuring dual A/V outputs, this monitor is capable of outputting the signal of both RF channels at the same time. It also features an A/V input as well as a Tracker Link port.
- Offering true 5.8GHz diversity, this device features automatic antenna switching to provide the best reception possible. A foldable screen shroud is included to optimize viewing in bright conditions.
Features:
- 800 x 480 High Resolution TFT LCD Screen
- In-built 5.8GHz Dual Switching Receiver
- Dual Buffered A/V Outputs
- Capable of Receiving 2 Different Channels Simultaneously
- Not Affected by 2.4GHz R/C Transmitter Signals
- Lightweight and Durable
- 9 Language Menu Selection
- 4 Bands and total 32 Channels
· CH1: 5705MHz CH1: 5733MHz CH1: 5865MHz CH1: 5740MHz
· CH2: 5685MHz CH2: 5752MHz CH2: 5845MHz CH2: 5760MHz
· CH3: 5665MHz CH3: 5771MHz CH3: 5825MHz CH3: 5780MHz
· CH4: 5645MHz CH4: 5790MHz CH4: 5805MHz CH4: 5800MHz
· CH5: 5885MHz CH5: 5809MHz CH5: 5785MHz CH5: 5820MHz
· CH6: 5905MHz CH6: 5828MHz CH6: 5765MHz CH6: 5840MHz
· CH7: 5925MHz CH7: 5847MHz CH7: 5745MHz CH7: 5860MHz
· CH8: 5945MHz CH8: 5866MHz CH8: 5725MHz CH8: 5860MHz
Specs:
- Screen Size: 7.0 inch
- Screen Type: TFT LCD
- Backlight Type: LED
- Resolution: 800 x 480
- Brightness: 450cd/m²
- Contrast: 500:1
- View Angle: 140/120° (Horizontal/Vertical)
- Working Voltage: DC 7~12V or 11.1V lipoly battery
- Working Temperature: -10°C ~ +65°C
- Power Consumption: < 8W
- Size: 180 x 120 x 23mm
- Antenna connection: SMA Plug (Pin inside)
Package Included:
- LCD Recevier * 1
- Antennas * 2
- AV Cables * 2
- Power Cable * 1
- Sunshade * 1
