500V 100A Wireless Voltmeter Ammeter Multimeter Voltage Ampere Power Watt Coulomb Capacity Time Temp

500V 100A Wireless Voltmeter Ammeter Multimeter Voltage Ampere Power Watt Coulomb Capacity Time Temp

Description:
Adopted 2.4G wireless transmission technology, this 500V 100A Wireless multi-function panel meter can display testing voltage, current, power, capacity, power consumption, temperature, operating time at the same time.

It is designed with 2 reserved relay connecting ports: one for battery charging and the other one is for discharging management. Meanwhile, it is built with over-voltage, insufficient voltage and over-current protection. It is easy to read values shown on the clear 2.4" LCD display.

Features:
- Achieve wireless data transmission to avoid troubles by disturbing wires
- With hall sensor that can achieve non-current detection, no need to disconnect the leads, safe, reliable and convenience;
- Display testing voltage, current, power, capacity, power consumption, temperature, operating time at the same time
- 18 Functions: NCP/ COP/ OVP/ LVP/ OUT/ LCK/ BAT/ BPC/ CER/ RET/ LNG/ STI/ SFH/ DEL/ FCH/ SNR/ SNT/ RFS; Various functions help you to get more accuracy testing result in operation
- With 2 reserved relay connecting ports: one for charging management and the other one for discharging
- Designed with memory function after power cut-off, parameter of AH and WH will be saved

Technical Parameters:
Input Voltage:
- Testing Range of Self Power Supply: 6-80V
- Testing Range of External Power Supply: 0-120V
- Testing Range of Input Current: 0-100A
- External Power Supply Voltage: 6-60V
- Display: 2.4" colorful LCD display

Testing Range:
- Voltage: 0.01V-120V
- Current: 0.1A-100A
- Capacity: 0.001AH-65000.00AH
- Power Consumption: 0.000KWH-9999KWH
- Time: 0-100 hours
- Power: 999KW
- Temperature: 0-100℃

Accuracy:
- Voltage: ±1%±2 digits
- Current: ±2%±5 digits
- Temperature:±1.5℃

- Rate of Testing Speed: 5 times/second
- Relay Delay Time: (0-60)S
- Transmission Distance: about 10 meters

Protection Type & Setting Range:
- OVP (Over-voltage Protection): 0.01-500V
- LVP (Less-voltage Protection): 0.01-500V
- OCP (Over-current Protection of Charging): 0-500A
- NCP (Over-current Protection of Discharging): 0-500A

Size:
- Display: 87*49*14mm
- Testing Panel: 114*54*28mm

Package Included:
- 1 x Display Module
- 3 x 2-Pin Wires
- 1 x USB 2.0 Cable
- 1 x Testing Module (includes Testing Panel, Hall Sensor)

Note: Temperature sensor is not included in this item. Thank you!
