ZM-3H2080 24V High Performance 3-Phase Stepper Motor Driver Controller AC80-220V for 86-130MM Stepper Motors
$166.32
ZM-3H2080 12V High Performance 3-Phase Stepper Motor Driver Controller AC80-220V for 86-130MM Stepper Motors
$166.32
ZM-3H2080 5V High Performance 3-Phase Stepper Motor Driver Controller AC80-220V for 86-130MM Stepper Motors
$166.32
Features:
- Supply voltage up to 50V
- Maximum output current can reach 4.2A(mean 3.0A)
- Three-state current control technology with low heating
- Automatic halving of static current 0.4 S to 60 %
- Two-phase stepper motor with 4, 6, 8 lines
- Optical isolation differential signal input, maximum pulse response frequency up to 200 KHz
- Subdivision accuracy 2,4,5,8,10,16,20,25,32,40,50,64,100,125,128 optional
- Small size(118 x 75.5 X 34mm)
- Convenient current setting, optional at eight
- Four dials for 15 steps
- Protection functions such as overpressure, short circuit etc..
- Bipolar constant current PWM driver output
- Suitable for all kinds of small and medium scale automation equipment and instruments, such as engraving machine, medical creep pump,
- Label striking machine, cutting machine, laser photo arrangement, plotter, CNC machine tool, automatic assembly equipment
- Wait a minute. It works well in devices where users expect small noise and high speed
II. Electrical, mechanical and environmental indicators
1. Electrical indicators
| parameter | MIN | Typical value | MAX | UNIT |
| Output current(peak) | 1.0 | -- | 4.2 | A |
| Input power (V) | 20 | 24/36 | -- | VDC |
| Control signal input current | 7 | 10 | 20 | mA |
| Step pulse frequency | 0 | -- | 200 | kHz |
| Insulation resistance | 500 | -- | -- | MΩ |
4. Strengthening heat dissipation
(1) The reliable working temperature of the actuator is usually within 60 ℃ and the working temperature of the motor is
Within 80 °C;
(2) It is recommended to choose an automatic half current mode when using and to reduce the current automatically when the motor stops
60 % to reduce heating of motors and drives;
(3) When installing the drive, use vertical side mounting to make the heat dissipation teeth stronger
Air convection; When necessary, install fans near the drive to ensure forced heat dissipation
The drive works within a reliable operating temperature range.
