9'' Underwater DVR Camera HD Fish Finder Recording 1000TVL 12 LED Light 100M Cable 8G TF Card

9'' Underwater DVR Camera HD Fish Finder Recording 1000TVL 12 LED Light 100M Cable 8G TF Card

Description:
- Color TFT LCD Screen.
- Metal housing:strong, durable and easily radiating.
- High resolution camera,clear picture,
- Night vision, and the lights can on/off.night lights adjustable.
- High quality special cable, waterproof and anti-corrosion/cold/tensile.
- 12V4500MA lithium battery.with battery capacity showing function:u can get the detail battery capacity when using.
- Special structure design make sure the camera is 100% waterproof.Waterproof Level: IP68
- With sun-visor for bright environment outside
- The product is an underwater video camera and fish finder,underwater breeding monitoring,fishing monitoring,underwater viewing,underwater adventure,water well monitoring

Specifications:
- Monitor:9 inch LCD
- Menu languages:multi-language
- Camera::high resolution
- Focus(mm):2.5mm
- Water proof:IP68
- Cable (diameter): 5MM
- Camera light source:12 LED with high while light(adjustable)
- Depth:100m
- Camera picture:color
- Monitor image:color
- Monitor input voltage:12VDC
- Sun-visor:removable
- Charger:AC100-240V,DC12.6V 1000MA
- Battery:lithium battery:12V4500MA
- Operation temperature:-20—60 degrees
- Storage temperature:-30—80 degrees
- Aluminum-box size:390x320x150MM
- Package size:410x360x160MM
- Gross weight:7KG

Cell box:
1.monitor video      2.battery indicator          3.power light    4.camera wire interface   5.power of monitor   6.power input for charger
7.light-degree adjustment for white light LED          8.power switch

Camera:
1.night-vision light     2.lens       3.cable      4.power wire interface     5.LED wire interface      6.video wire interface

Charging:
When the battery power is low,it needs charging,and the method is as below:
1.Take out the battery and charger from the box.
2.Connect the charger to the battery(red to red, black to black).
3.Connect the charger to the alternating current of 110-200v.The red indicator means charging.
4.The green indicator means finishing charging.

Notes:
1.to make sure the battery using age longer, please recharge it timely; otherwise, it will make it can not recharged.
2.Please keep distance from the system when charging

Package List:
- 1 x Camera with 100m Cable
- 1 x 7''Display
- 1 x Charger
- 1 x Cell box
- 1 x Aluminum box
- 1 x Monitor
- 1 x Sun shade
