AD8361 Mean Response Power Detector Module Low Frequency 2.5GHz for DIY

Availability: In stock, usually dispatched in 1 business day

  • Price:$16.64
  • Price in reward points: 166 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $16.31 $15.97 $15.48 $14.81 Contact US
Quantity:
Buy it now Add cart

You might like

AD8313 Module Multistage Demodulation Logarithmic Amplifier 0.1-2.5GHz Logarithmic Detector Module

AD8313 Module Multistage Demodulation Logarithmic Amplifier 0.1-2.5GHz Logarithmic Detector Module

$17.49

(0)
ADL5511 RF Envelope Detector TruPwr RMS Detector Pulse Detector Measurement Module 6GHz 245380A_Y272

ADL5511 RF Envelope Detector TruPwr RMS Detector Pulse Detector Measurement Module 6GHz 245380A_Y272

$64.92

(0)
LMX2594 Frequency Synthesizer Module PLL 10M-15GHz High Frequency Microwave Signal Generator

LMX2594 Frequency Synthesizer Module PLL 10M-15GHz High Frequency Microwave Signal Generator

$693.63

(0)
PM2.5 Air Particle Dust Sensor Laser Digital Output Detector Module Air Purifier SDS018

PM2.5 Air Particle Dust Sensor Laser Digital Output Detector Module Air Purifier SDS018

$34.80

(0)
LMX2594 Frequency Synthesizer 10M-15GHz HF Microwave Signal Generator + USB Official Control Board

LMX2594 Frequency Synthesizer 10M-15GHz HF Microwave Signal Generator + USB Official Control Board

$264.66

(0)
OWON XSA1015P-TG 9KHz-1.5GHz Portable Spectrum Analyzer Tracking Generator with 10.4-inch LCD Touch Screen

OWON XSA1015P-TG 9KHz-1.5GHz Portable Spectrum Analyzer Tracking Generator with 10.4-inch LCD Touch Screen

$1,094.74

(0)
KDT5511-019 ADL5511 6GHz RF Envelope Detector Pulse Detection Measurement Module AM Demodulation

KDT5511-019 ADL5511 6GHz RF Envelope Detector Pulse Detection Measurement Module AM Demodulation

$68.34

(0)
True RMS Response Power Detector AD83622 50MHz-3.8GHz Fully Shielded Shell Detect Wide-Band Power

True RMS Response Power Detector AD83622 50MHz-3.8GHz Fully Shielded Shell Detect Wide-Band Power

$30.41

(0)

AD8361 Mean Response Power Detector Module Low Frequency 2.5GHz for DIY

Specifications:
- Name: AD8361 Module Mean Response Power Detector
- Size: 33*17mm
- Power supply: 5V

Chip Features:
- Calibrated root mean square response
- Input range up to 30dB (2.5GHz)
- Maximum input: 700mV rms,10dBm (50Ohm)
- Linear response -+0.25dB
- Single power supply: 2.7-5.5V
- Low power consumption: 3.3mW (3V)
- Fast shutdown mode: <1uA

Package List:
- 1 x AD8361 Module
