ARM-21N3 Mechanical Arm 6 DOF Robot Arm Industrial Robotic Arm Unassembled w/ 20Kg Digital Servos

Availability: In stock, usually dispatched in 1 business day

  • Price:$137.17
  • Price in reward points: 1372 Reward Points: 14
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $134.43 $131.68 $127.57 $122.08 Contact US
Quantity:

ARM-21N3 Mechanical Arm 6 DOF Robot Arm Industrial Robotic Arm Unassembled w/ 20Kg Digital Servos

Features:

- Upgraded 6-DOF industrial robot arm
- All movable joints connected by bearings
- 9-year manufacturing experience ensures product quality
- Gripper holder fits suction cups, electromagnets, forks, craws, grippers, etc.
- Comes with 20kg digital servos

20KG Digital Servo:

- Servo board: Digital controller
- Servo size: 40 x 20.5 x 40.5mm/1.6 x 0.8 x 1.6"
- Weight: 56g±5% (0.1lb±5%)
- Working voltage: 4.8-7.2V
- Output transmission: metal gears + double bearings
- No-load speed: 0.14-0.18sec/60°
- Stall torque: 20.5kg.cm
- Pulse width: 500-2500usec
- Rotation angle: 180°
- Dead zone width: 5usec
- Midpoint position: 1500usec
- Output shaft: 25T
- Output shaft hole: M3
- Idling current: 210-260mA
- Blocking current: 2100-2700mA
- Waterproof level: preliminary
- Shell: aluminum alloy + plastic

Package Included:
- 1 x Set of Robot Arm

Note:
- Assembly is needed, providing assembly instructions.
- Control circuits, suction cups, grippers and other accessories mentioned above are not included.
