AT430TAC V5.4 4.3" LCD AHD2.0/TVI3.0/HD TVI2.0/CVI2.0/TVI HD Camera Security Tester

AT430TAC V5.4 4.3" LCD AHD2.0/TVI3.0/HD TVI2.0/CVI2.0/TVI HD Camera Security Tester

Product Description:

- HD2.0/TVI3.0/CVI2.0,TVI support 500W,analog video signal,4 in 1 mode.Support analog video colour bar output,display signal standard.
4400MA li-on battery,working more than 8 hours.
- Support coaxial sight control protocol,no need 485,can control dome.12V/800MA output.

Main parts:
1.ABS shell
2. 4.3'' LCD screen 480*272
3.Battery 2pcs 18650,2200mAH/pcs,total 4400MA
4.Main board
5.decode module
6.Holding belt

Input/output display:
1.TVI2.0 1280*720@25/30/50/60fps(720P 1.3MP)
1280*720@25/30fps(720P 1.3MP) V2.0
1920*1080@25/30fps(1080P 2MP)
TVI3.0 2048*1536@18 fps (3MP)
TVI4.0 2560*1944@12.5fps (NTSC/PAL) (5MP balck/white)
2.AHD2.0 1280*720@25/30fps(720P 1.3MP)
1920*1080@25/30fps(1080P 2MP)
AHD3.0 2048*1536@18fps(3MP)
2560*1440@15fps(4MP)
3.CVI2.0 1280*720@25/30/50/60 (720P 1.3MP)
1920*1080@25/30 (1080P 2MP)
4.Analog CVBS signal PAL /NTSC input/output
AT430TAC V5.4:
TVI 720P@25/30/50/60:Yes
TVI 1080P@25/30:Yes
TVI 3MP@18:Yes
TVI 4MP@25/30:NC
TVI 5MP12.5/20:NC
AHD 720P@25/30:Yes
AHD 1080P@25/30:Yes
AHD 3MP@18:Yes
AHD 4MP@15:Yes
AHD 4MP@25/30:NC
AHD 5MP@20:NC
CVI 720P@25/30/50/60:Yes
CVI 1080P@25/30:Yes
CVI 4MP@25/30
CVBS analog video:Yes
VGA input:NC
HDMI input:NC
TVI coaxial sight control HIKVISION-C protocol:Yes
CVBS video colour bar output:Yes

Charging & output:
1. Battery group the max voltage:4.2V,2pcs 18650 parallel connection.
2.The max output 12V/800mA
3.Standard signal colour bar output,NTSC or PLA auto output,default PAL

Note:you switch on the power,when there is no camera input signal,the colour bar output is PAL.
Connect the camera signal,output colour bar standard depends on the camera standard.

Power consumption:
The max power consumption for device:2.5W (when it doesn't connect 12V load,the machine automatically consump power)
12V output the max power consumption:9.6W

Main unit max size:118x90x47MM
Net weight:280g
Gross weight:1.0kg

Package List:
- 1 x Tester Host
- 1 x Charger cable
- 1 x BNC adapter
- 1 x USB-A/V+DC cable
- 1 x Manual
