ATTEN AT936b Soldering Station Rework Station Solder 50/60Hz 50W (200'C~480'C) AT300049

 ATTEN AT936b Soldering Station Rework Station Solder 50/60Hz 50W (200'C~480'C) AT300049

Characteristics and Advantages
- Split design, small size, easy for putting, space- saving in particular.
- Light handle and suitable for long-time operation
- Heater with imported temperature - beard materials, four-wire heating method, long life, and low cost.
- Low-voltage power supply used on the  heater, anti-static, no creepage, no interference
- Unique temperature locking devices to prevent the
- staff from adjusting the temperature improperly.
- Temperature 200-480°C, stable and accurate
- Same as the soldering tips of international brand;

Technical Specifications
- Input Voltage: AC 110V/220V optional
- Input Frequency: 50/60Hz
- Power Consumption: 50W (max)
- Temperature Range: 200 – 480°C
- Tip and ground impedance: <2 Ohm
- Tip and ground potential: <5mV
- Standard tip: AT-900M

ATTEN INSTRUMENTS
- RF Microwave Instruments
- RF Microwave Components
- Spectrum Analyzers.Regulated DC Power Supply
- Switching DC Power Supply.Digital Storage Oscilloscope
- Signal Generator.Attenuator.Amplifier.850 Rework Station
- 936 Constant Temp Soldering Station
- Electronic Instruments.Electronic Tools

Safety Precautions
- Caution: Improper usage can cause serious injury to personnel and/or damage to equipment. For
- personnel safety, please follow these precautions:
- Never use it to do other work except soldering.
- Do not subject the main unit to physical shock. Never drop or sharply jolt the unit.
- Don't change the device at will
- Replace loss items with original accessories of ATTEN.
- Don't put it in water or operate with wet hands
- Don't pull the cable but hold tightly the plug when you take it out of plug.
- Please keep the operate place well ventilated since soldering process produce smoke.
- Don't play with other people or would be easy to hurt others or yourself.

Care and Maintenance
- Keep the soldering station dry; if it gets wet, dry it immediately.
- Use the soldering station only in normal temperature environments.
- Keep the soldering station away from dust and dirt.
- The soldering iron tip should be cleaned after use by wiping it on the damp sponge found in the soldering - iron stand. This is to get rid of burnt solder or fluxes that cause oxidation on the tip.

Changing Soldering Tip
- Always turn the power OFF when removing or inserting a tip
- Let the tip to cool down to room temperature before holding it with heat resistant pads
- Unscrew the metal cap nut
- Pull out the shaft of the soldering iron
- Replace it with a new soldering tip.
- Put back the shaft and securely lock with the metal cap nut

Package includes:
- Soldering station x 1
- Iron base x 1
- Cleaning sponge x 1
- Handle x 1 group
- Power cable x 1
- Manual x 1
