Automatic Start Generator Control Panel Diesel Generator Controller For Various Genset Applications

Automatic Start Generator Control Panel Diesel Generator Controller For Various Genset Applications

Description:
It is an Automatic Mains (Utility) Failure Control Module suitable for a wide variety of single diesel or gas genset applications. Monitoring an advanced list of engine parameters, it will automatically shut down engine, or indicate a warning, on detection of a fault condition, indicating the fault on the module’s front panel LCD display or LED. The module can be easily configured using the 810 interface and PC. Front panel editing is also available.

Key Features:
• PC/Front panel configuration
• Digital and analogue inputs
• Digital outputs
• Automatic mains (utility) supply monitoring
• Automatic shutdown or warning when fault conditions are detected
• Automatic/Manual/Remote start
• Engine pre-heat
• Engine monitoring and protection features
• Protected Solid State (PSS) outputs
• Tamper-proof engine hours counter
• LED indicators
• Configurable timers
• Configurable outputs
• Configurable inputs
• Back-lit character/icon LCD display

Key Benefits:
• Automatic transfer between mains (utility) and generator power
• On-site module configuration and remote configuration (max. 100m/328.1ft) using DSE PC software
• User-friendly set-up and button layout
• Multiple engine parameters are monitored simultaneously
• License-free PC software

Specifications:
- Speed sensor frequency range: 1Hz-10KHz
- Speed sensor voltage range: minimum +/-0.5V (during startup) -70V
- Fuel relay output A: 15Amp DC output
- Start electrical output B: 15 Amp DC output
- Relay output C and D: 8Amp 250V passive contact output
- Custom output E, F, G and H: 2Amp DC output
- Panel hole spacing: 220 x 160mm/8.7 x 6.3"

Package Included:
- 1 x Set of Generator Control Panel
