B200 50MHz-6GHz SDR Development Board Software Defined Radio Platform for Opensource Learning Replacement for Ettus B200
Description:
- The B200 provides a fully integrated, single board, universal software radio peripheral platform with continuous frequency coverage from 50MHz - 6GHz.
Features:
- The first fully integrated USRP device with continuous RF coverage from 50MHz - 6GHz.
- Full duplex operation with up to 56MHz of real time bandwidth (61.44MS/s quadrature).
- Fast and convenient bus-powered connectivity using SuperSpeed USB3.0.
- For GNURadio and OpenBTS support through the open-source USRP Hardware Driver (UHD)
- Open and reconfigurable for Spartan 6 XC6SLX75 FPGA with free tools for Xilinx (for advanced users).
- Early access prototyping platform for the Analog Devices AD9364 RFIC, a fully integrated direct conversion transceiver with mixed signal baseband.
- It is cost-effective and suitable for radio enthusiasts communication research.
Specification:
- Type: 1R1T single channel transceiving duplex RF development board
- Firmware software: fully compatible with UHD firmware and software
- For FPGA chip: XC6SLX75
- USB interface: USB Type-B 3.0
- Simultaneous interface: 10M, 1PPS, GPSDO interface
- AD chip: AD936X
- Secondary development: support
Input/Output:
- DC voltage input: 5V
Conversion Module Parameters:
- ADC sampling rate (maximum): 61.44MS/s
- ADC resolution: 12bits
- ADC SFDR: 78dBc
- DAC sampling rate: 61.44MS/s
- ADC resolution: 12bits
- Maximum rate with host (16b): 61.44MS/s
- Local oscillator accuracy: ±2.0ppm
- Unlocked TCXO accuracy: ±7.5 ppm
Single-Channel RF Performance Parameters:
- Single sideband signal/image rejection: -35/50dBc
- 3.5GHz: 1.0degRMS
- 6GHz: 1.5degRMS
- Output power: >10dBm
- Input third-order intercept point: -20dBm
- Noise figure: <8dB
Physical Attributes:
- Size: 9 x 6 x 1.5cm
- Product weight: 40g
Package Included:
- 1 x B200 Development Board
