Car Chassis 4WD Track Caterpillar Chassis for Arduino DIY Toy Robot Car RC Tank C300

Car Chassis 4WD Track Caterpillar Chassis for Arduino DIY Toy Robot Car RC Tank C300

Introduction:
A novel design has already coming for the tank chassis, with beautiful shape, and full metal aluminum alloy structure. In this car chassis, a space for 9g servo is left for the ultrasonic sensor, and a space for MG995 servo is also left to rotate the mechanical manipulator. What’smore, UNO R3 and NodeMCU development boards are also designed to install. In addition, the metal panel can be used to install the wheeled car by install the 25mm and/or 37mm motor frames. Interesting, a LED light is installed to brighten the dark in the night. Under the help of the motor, the tank chassis can be smoothly turn left, right, circle, forward and backward, ect. Therefore, when you get the chassis, it can do many things for you, like getting the temperature and mobile monitor. Certainly, we have developed a series of car/tank chassis. Hoping you can choose your loved car chassis.

Features:
- Noveland elegant appearance;
- Aluminum alloy;
- Solid structure;
- Powerful force;
- Quickly,stability, flexibility;
- Strong power;

Specifications:
- Name: C300 Intelligent car / tank chassis
- Material: aluminum alloy
- Wheel: Rubber ( blue ,black,red color, pls choose the coloryou want)
- Product size: about 200*120*70mm (L *W* H)
- Weight: 1000g
- Load weight: 2.5kg

Installation interface:
- Reserve the space for 9g, MM95, MM96R servo
- Reserve the intallation holes for UNO R3 and NodeMCU development board kit;
- Reserve the space for robotic manipulator;
- Design two LED light holes for the dark moving and brighten the light;
- Add the 25mm and 37mm motor frame, can change the 4WD smart car;

Motor Parameters:
- Name:25mm gear motor
- Output speed: 150±10%rpm
- No load current: 200mA (Max)
- Stall current: 4500mA(max)
- Stall torque: 9.5kgNaN
- Rated speed: 100±10%rpm
- Rated torque: 3000gNaN
- Rated current: 1200mA (Max)
- Noise :56dB
- Working voltage: 9V
- Outside Shaft Length: 14.5mm
- Shaft End Play: 0.05-0.50mm
- Screw Size: M3.0
- Dia. Of Shaft phi 4mm, D3.5
- Encoder: 2pulses/circle

Shipping List:
- Chassis:1 pcs
- Wheels: 4 pcs
- Copper couplings: 4 pcs
- DC motor: 4 pcs
- Motor bracket: 4 pcs
- Screws
