• CJMCU-MPU9255 9DOF 9Axis AIO Altitude Module Substitue MPU9250/MPU9150

CJMCU-MPU9255 9DOF 9Axis AIO Altitude Module Substitue MPU9250/MPU9150

Availability: In stock, usually dispatched in 1 business day

  • Price:$16.48
  • Price in reward points: 165 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $16.15 $15.82 $15.33 $14.67 Contact US
Quantity:

CJMCU-MPU9255 9DOF 9Axis AIO Altitude Module Substitue MPU9250/MPU9150

CJMCU-9255:

1 Gyroscope Features
- The triple-axis MEMS gyroscope in the CJMCU-MPU9255 includes a wide range of features:
- Digital-output X-, Y-, and Z-Axis angular rate sensors (gyroscopes) with a user-programmable full-scale range of ±250, ±500, ±1000, and ±2000°/sec and integrated 16-bit ADCs
- Digitally-programmable low-pass filter
- Gyroscope operating current: 3.2mA
- Sleep mode current: 8μA
 Factory calibrated sensitivity scale factor
- Self-test

2 Accelerometer Features
- The triple-axis MEMS accelerometer in CJMCU-MPU9255 includes a wide range of features:
- Digital-output triple-axis accelerometer with a programmable full scale range of ±2g, ±4g, ±8g and ±16g and integrated 16-bit ADCs
- Accelerometer normal operating current: 450μA
- Low power accelerometer mode current: 8.4μA at 0.98Hz, 19.8μA at 31.25Hz
- Sleep mode current: 8μA
- User-programmable interrupts
- Wake-on-motion interrupt for low power operation of applications processor
- Self-test

3 Magnetometer Features
- The triple-axis MEMS magnetometer in CJMCU-MPU9255 includes a wide range of features:
- 3-axis silicon monolithic Hall-effect magnetic sensor with magnetic concentrator
- Wide dynamic measurement range and high resolution with lower current consumption.
- Output data resolution of 14 bit (0.6μT/LSB) or 16 bit (15μT/LSB)
- Full scale measurement range is ±4800μT
- Magnetometer normal operating current: 280μA at 8Hz repetition rate
- Self-test function with internal magnetic source to confirm magnetic sensor operation on end products
