• CM-01B Vibration Sensor PVDF Sensor + 30cm Shielded Cable for Electronic Stethoscope Body Sounds

CM-01B Vibration Sensor PVDF Sensor + 30cm Shielded Cable for Electronic Stethoscope Body Sounds

Availability: In stock, usually dispatched in 1 business day

  • Price:$40.08
  • Price in reward points: 401 Reward Points: 4
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $39.28 $38.48 $37.27 $35.67 Contact US
Quantity:

CM-01B Vibration Sensor PVDF Sensor + 30cm Shielded Cable for Electronic Stethoscope Body Sounds

Description:

The CM-01B contact microphone is composed of a piezoelectric film (with high sensitivity and stable performance) and a low noise preamplifier circuit. It provides a unique pickup of sound and vibration signals in a buffered output.

In the structural design of the product, we try to minimize external noise interference. When the rubber pad in the middle of the product receives a vibration signal, it can output a highly sensitive signal.

The CM-01B is an ideal sensor for monitoring body sound.

Features:
- High sensitivity
- Stable performance
- Low noise
- Piezoelectric film technology
- With a lead-out shielded cable
- Sturdy and durable
- Wide frequency band
- Good impact resistance and excellent performance
- Light weight and low cost
- The amplitude of the sensor output signal is about 100mV

Applications:
- Electronic stethoscope
- Bone conduction pickups
- Universal contact microphones
- Vibration/shock monitoring

Wiring:
- Silver wire: to power supply GND.
- Red wire: to power supply VCC.
- White wire: signal output.

Package Included:
- 1 x Vibration Sensor + 30cm Shielded Cable

Packaging Details:
- Weight: 0.25kg
