DHLG-03X High Torque Servo 700KG.CM Unmanned Vehicle Intelligent Steering Remote Control Models

DHLG-03X High Torque Servo 700KG.CM Unmanned Vehicle Intelligent Steering Remote Control Models

DHLG-03X Video Description:
https://v.youku.com/v_show/id_XNTE0OTYxMTMyMA==.html

Product Specifications (Download):
http://pan.baidu.com/s/1kUZusM7
Password: apdt
(The torque and weight parameters are not subject to the manual, this is a shared manual)

Description:
It features super stable, smooth running, and super anti-interference ability.

The unique power stabilization technology guarantees the continuous operation of the servo, which is completely different from the fuse protection on other servos. Once the fuse is blown, the servo cannot continue to work. While our servo can work stably within safe torque. Never drop the connection.

Product Features:
* Suitable for servo controller, model airplane remote control, analog voltage control
* Alloy gear high torque motor
* Aluminum alloy gearbox is ultra-lightweight
* Easy to install, durable, reliable, stable and practical

Application:
* Large robots, mechanical arm power joints
* Industrial robot automation
* Precise control of valve angle
* Large camera pan/tilt
* Large remote control car model, remote control ship model

Attention:
Please test various application scenarios by yourself, and use them after the test is qualified. Please use large-scale testing for various application scenarios by yourself. We are not responsible for the consequences of this!

Technical Parameters:
- Servo model: DHLG-03X
- Maximum torque: 700KG.CM
- Net weight: 4.5KG
- Rated voltage: DC24V (30V/MAX limit voltage)
- No-load current: <500MA (Current limit value is 20A, 30A switching power supply or battery is recommended. Batteries not included)
- Limit angle: L: 1.0-2 MS control mode: 360 degrees (adjustable electronic limit). H: 0.5-2.5MS control mode: 360 degrees (electronic limit adjustable)
- Control mode: 1.0-2.0MS pulse mode: suitable for the control of the model airplane remote control receiver. 0.5-2.5MS pulse mode: suitable for multi-channel steering gear controller control (pulse frequency: 50-333HZ)
- Material: Gear and shaft: Alloy steel. Gear box body: alloy steel
- Mechanical life: >6000000 times/normal torque
- Speed: 0.5S/60 degrees
- Size: As the picture shows

Package Included:
- 1 x Servo

Note:
- Battery is not included.
