Digital Display Tachometer Communication Tachometer RS485 Revolution Meter ZNZS6EIR-M485
Description:
- ZNZS-6E1R-M485, with 485 communication port, and pulse equivalent setting, and shutting down alarm output, movement launched alarm output.(measuring value larger than setting value)
- Dimension: 48*96*75MM,
- Hole dimension: 45*92*75MM
One group relay output(OUT1 output)
- Range of speed: -9999----999999
- Can calculate: pulse equivalent: 0.001-9999,
- Can be set as tachometer(n/min) and linear speed table(mm/s)
- Can locate the decimal point
Parameter:
- Power supply: AC/DC 100-250V
- Output power supply:DC12V 100mA(for sensor use)
- Input signal frequency: 0-30KHz
- Input signal: L<=2V H>=4V, pulse length>=20uS(30K CPS)
- Weight: 120g/200g
- Consumption:<4W
- Trigger capacity: AC220V 3A DC24V,5A
- Reset impulse signal: impulse voltage<=2V, impulse width>=4mS
- Input resistance: 4.7K
- Environment: temp 0-60degree, relative humidity<=85%
- Storage temp: -20---85degree
- Installation: snap in
