Digital Temperature Controller STC-100A 24V Cold Room Low Price Digital Thermostat -40-110 Degree

Availability: In stock, usually dispatched in 1 business day

  • Price:$16.61
  • Price in reward points: 166 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $16.28 $15.95 $15.45 $14.78 Contact US
Quantity:

Digital Temperature Controller STC-100A 24V Cold Room Low Price Digital Thermostat -40-110 Degree

Description:

Range:-40~99oC
Mounting size:71*29mm
Output: Refrigerating, Heating
Retrun difference
Compressor delay protection
All-purpose Temperature Controller STC-100A

Features:
Temperature measure and display; heating and cooling control; switch between heating and cooling; temperature control point and return difference setting; compressor delay; temperature upper and lower limit; temperature calibration; temperature sensor error alarm. Easy operation, suitable for seafood machine etc.

Technical Parameters:
  1.Power supply: 220VAC+10%-15%,50/60Hz
  2.Power consumption: <3W
  3.Temperature measuring and controlling range: -40~+99oC
  4.Resolution: 1oC
  5.Accuracy:  ±1oC
  6.Relay output capacity:10A(0.5HP)/220VAC
  7.Delay time when sensor error: 1 min
  8.Sensor type:  NTC sensor
  9.Safety level of the front panel: IP54
10.Operating temperature:  0~+60oC
11.Storage temperature:  -30~+75oC
12.Relative humidity: +20%~+85%(No condensate)
