DSO1062B 60MHz 2CH Handheld Oscilloscope Multimeter 1GSa/s 5.6 Inch TFT Color LCD OSC

DSO1062B 60MHz 2CH Handheld Oscilloscope Multimeter 1GSa/s 5.6 Inch TFT Color LCD OSC

Feature
- 60MHz Oscilloscope, 1GS/s sample rate, and 6000 Counts DMM with analog bargraph.
- 1M Memory Depth.
- High Refresh Rate (2500 frames).
- Large 5.6 inch TFT Color LCD Display; High Resolution(640*480); Dual-Window Design --More clear, More Detailed
- One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform.
- Easy-to-use pop-up menu with built-in multi-language help system.
- 32 Automatic Measurements.
- Waveform Math: Add, Subtract, Multiply, and Divide.
- Store and recall over.
- Automatic cursor tracking measurements.
- XY Mode.
- Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems.
- Waveform Recorder to collect/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames.
- Pass/Fail function compares a stored waveform to an unknown input.
- Average Mode for smoothing waveforms.Square Wave Output (2V, 1kHz) for probe adjustment.
- USB Host/Device 2.0 full-speed interface; support removeable disk;  LAN Option, easy to control by PC or long-distance.
- Dimensions (mm): 240(L)x165(W)x50(H), be carried easily.


Package content:
- 1 x DSO1062B Oscilloscope unit
- 1 x Connecting Line
- 1 x USB Cable
- 1 x Installation CD
- 1 x Probe
- 1 x Power cable
- 1 x Carry bag
