DT-920 Compact Digital Multimeters 2000 920N 920L LCD Display Auto-ranging
Description:
DT-920/920N/920L/921/921N/922 Compact Digital Multimeters
DT-920/920N/920L/921/921N/922 series are Compact Multimeters with double molded plastic housing and over sized high contrast 2000/4000 counts LCD display. They’re all CAT Ⅲ rated for 600V and have auto-ranging function and provide 0.5% basic DCV accuracy.
Safety Conformance
EN61010-1 CAT III 600V, CAT II 1000V
Double molded plastic housing
Full ranges protection
Features:
|
|
920/920N/920l |
921/921N |
922 |
|
Digital display counts |
2000 |
2000 |
4000 |
|
Safety design |
﹡ |
﹡ |
﹡ |
|
Data Hold |
﹡ |
﹡ |
﹡ |
|
Auto Ranging |
|
﹡ |
﹡ |
|
Auto Power Off |
|
|
﹡ |
|
Max Hold |
|
﹡ |
|
|
Non-contact ACV detection |
920N |
921N |
|
|
Backlight LCD display |
920L |
|
Specifications:
|
Function |
Max. Range |
Accuracy |
920/920N/920l |
921 |
922 |
|
Voltage DC |
600V |
±0.5% |
﹡ |
﹡ |
﹡ |
|
Voltage AC |
600V |
±1.2% |
﹡ |
﹡ |
﹡ |
|
Current DC |
10A |
±2.5% |
﹡ |
﹡ |
﹡ |
|
Current AC |
10A |
±3.0% |
|
﹡ |
﹡ |
|
Resistance |
2MΩ/20 MΩ/40 MΩ |
±0.8% |
2MΩ |
20 MΩ |
40 MΩ |
|
Capacitance |
100μF |
±3.0% |
|
|
﹡ |
|
Frequency |
10MHz |
±1.5% |
|
|
﹡ |
|
Temperature |
760℃ / 1400℉ |
±3.0% |
|
﹡ |
﹡ |
|
Duty Cycle |
99.9% |
±1.2% |
|
|
﹡ |
|
Diode and Continuity |
Yes |
||||
|
Size (H*W*D) |
150mm*70mm*48mm |
||||
|
Weight |
255g |
||||
Accessories:
- Test Leads, 9V Battery, Type K temperature probe（921/922）, Gift Box with carrying case.
