ETCR6100 AC/DC Clamp Meter 0-1000A High Accuracy Digital Ammeter LCD Display for Current Leakage Detection

ETCR6100 AC/DC Clamp Meter 0-1000A High Accuracy Digital Ammeter LCD Display for Current Leakage Detection

Description:
- ETCR6100 AC/DC Clamp Current Meter suitable for measuring AC, DC leakage current below 600V, range: AC/DC 0.0A~1000A, CT size: 30mmx35mm, especially suitable for places with dense flat cable (power metering system, high-speed rail system, automobile circuit maintenance, etc.). Non-contact current measurement, safe and simple operation.The instrument is small size, high accuracy, performance stable and function perfect, which is one of the necessary tools for electrician safety inspection and maintenance.
- The instrument with data hold, data storage and other functions, can store 99 groups of data, the instrument connect computer by interface, storage data can be uploaded to the computer, easy to read, analysis, save, print and so on.

Specification:
- Model: ETCR6100
- CT size: 30mm x 35mm
- Range: DC/AC 0.0A ~ 1000A
- Accuracy: ±2%rdg±3dgt
- Resolution: 0.1A
- Meter size: 175mm x 70mm x 38mm
- Meter weight: 200g
- Working current: 10mA
- Function: measurement of DC current, AC current, peak hold, on-line monitoring
- Power supply: 6LR61 9V
- Test mode: clamp CT, Non-contact measurement
- Display mode: 4digits LCD display
- LCD dimension: 35mm x 21.5mm; display area: 32mm x 15mm
- Sampling rate: about 2 times/s
- Frequency: AC 45Hz ~ 400Hz
- Polar indication: automatic identification for DC current detecting, display "-" symbol
- Wire position: the tested wire should be in the center of the clamp jaw, clamp with off-center position will increase the error for max 1.5%rdg
- Shift: automatically
- Line voltage: line measurement below DC 600V
- Software: Yes, the storage data of the meter can upload to computer by software.
- Data storage: 99 groups, flashing display FULL symbol indicate storage is full.
- Peak hold: peak value capture and hold function, during the testing, long press the HOLD key to display the peak value.
- Data hold function: DH symbol display
- Overflow display: exceed measure range overflow function: OL symbol display
- Auto shut down: 5 Minutes after power on, the meter shuts down automatically without any operation to reduce battery consumption.
- Battery voltage: while battery voltage decreases to around 7.2V, will display low battery voltage symbol, and remind to replace the battery.
- Working temperature: -10℃ ~ 50℃, below 80%RH
- Limit temperature error: -10℃ ~ 0℃ and 40℃ ~ 50℃, the maximum increase in error is 2%rdg
- Storage temperature: -10℃ ~ 60℃, below 70%RH
- Insulating strength: AC2KV/rms (between the core and outside shell)
- Suitable safety standard: IEC1010-1, IEC1010-2-032, pollution, etc 2, CAT Ⅲ(600V)

Package Included:
- 1 x Clamp Meter
- 1 x RS232 Cable
- 1 x User Manual

Note:
- Battery is not included.
