- It supports HDMI/AV/Ypbpr Input and 1080P HD Video Recorded into USB Flash/HDD/SD cards.
- New Selling Point : This unit support voiceover function when recording videos.
- Two Colors optional : White or Black+Red, delivery based on stocks.
- For PS4, if your PS4 don't have HDCP protection, it could be used to connect with this HDMI game acquisition for recording directly. If it's old version of ps4 with HDCP protection, buyer need a HDMI splitter to disable HDCP protection or need to make setup with PS4 firmware to disable the HDCP protection (We have introductions for PS4 as below).
- If any further question or misunderstanding, you can check with us before order it.
Connections:
- Interface USB 2.0 Host, SD Card
- Video Input Digital: HDMI
- Analog: Component Video, Composite Video
- Audio Input Digital: HDMI
- Analog: RCA L/R, 3.5mm MicroPhone In
- Note:Microphone without pass through fo HDMI input
- Video Output Digital: HDMI (Pass-through from HDMI or Component or Composite Input)
- Audio Output Digital: HDMI (Pass-through from HDMI or RCA L/R Input)
- Analog: 3.5mm Stereo (Pass-through from HDMI or RCA L/R Input)
Applicable Connections with Game Consoles:
- HDMI WiiU, Xbox 360, Xbox One, PS4
- Component WiiU, Xbox 360, PS3
- Composite WiiU, Xbox 360, PS3
- Note: HDCP contents cannot be recorded.
Hardware Extra:
- Codec Hardware MPEG4 encoder
- User Interface On-board Hot Button for one-click recording
- LED indicator for working status
- Dimensions 140(L) × 74(W) × 23(H) mm
- Weight 115g
Standards:
- Storage Media USB Flash Disk, Portable Hard Disk, SD Card
- Max Capacity: USB / 2T, SD / 64G
- Note:The exFAT format is not supported.
- Resolution Input / Pass-through: 720 x 480 (60p), 720 x 576 (50p), 1280 x 720p (50p), 1280 x 720p(60p), 1920 x 1080 (50i), 1920 x 1080 (60i), 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p), 1920 x 1080 (50p), 1920 x 1080 (60p)
- Acquisition: 720 x 480 (60p), 720 x 576 (50p), 1280 x 720p (50p), 1280 x 720p(60p), 1920 x 1080 (50i), 1920 x 1080 (60i), 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p), 1920 x 1080 (25p), 1920 x 1080 (30p)
- Note:Upscaling is not supported.
- Record Format Video: MP4, Audio: AAC Stereo
- Record Quality Max: 18Mbps@1080P 30fps
- Record File Max: 2GB / Per File, With RTC (Real Time Clock)
- Record Place Max: 140MB / Minute, 8.4GB / Hour
- Power Supply USB DC 5V / 2A
Video link on YouTube
About setup
About quality review
Applications:
- Software Arcsoft Showbiz
- Video Editing Timeline / Storyboard edit, Split / Divide Scenes, Multi Trim Scenes …
- Video Export Upload to YouTube
- Portable Device: iPod, iPhone, iPod Touch, Apple TV, PSP, PS3, Xbox
- File: MPEG 1 / 2 / 4, WMV HD, Quicktime (MOV) …
- Operating System Windows 8 (32 / 64 bit), Windows 7 (32 / 64 bit), Windows Vista (32 / 64 bit)
- CPU Intel Core 2 Duo 2.8GHz, AMD Athlon 64X2 Dual Core 3.0GHz
- Memory 4 GB RAM
- Graphics Card VGA card with support for DirectX 10.0c or above
Note:Product shell color in video is white because of the sample,and standard is Black/Red.
Package Contents:
- 1 x Device HD Video Card
- 1 x AV cable adapter
- 1 x MINI USB Power Supply
- 1 x Remote Control
- 1 x User Manual
