FX3U-32MR-407 China-Made PLC Control Board PLC Industrial Control Board with Shell for Siemens

FX3U-32MR-407 China-Made PLC Control Board PLC Industrial Control Board with Shell for Siemens

Features:
- PLC controller made in China
- Software programming for Mitsubishi
- Three-year warranty
- Stable performance
- Reliable quality
- Cost-effective

Specifications:
- Product model: FX3U-32MR-407
- Output type: Relay
- Pulse output: None
- Stepper motors: Not supported
- Output current: 5A
- Net weight: 331g/0.7lb
- Product size (MAX.):14 x 8.85 x 6.2cm/5.5 x 2.2 x 2.4"
- Switch quantity: 16 inputs and 16 outputs
- Rated power: 24V 5W
- Input signal: 0V valid/low potential/NPN
- Output signal: COM input voltage is equal to the output voltage
- Supply voltage: DC24V (do not input AC or 220V)
- High-speed counting: 6 channels counting, default 12K, selectable 60K (1 channel AB counting)
- Floating point: Supported
- Memory capacity: 32,000 steps
- Downloading method: direct downloading (computers with serial port: DB9 cable; computers without serial port: USB to serial port cable)
- MODBUS: Supported
- RS485 communication port: Supported
- Connecting touch screen: Supported
- Connecting text screens: Supported
- Programming software: For GX Developer or GX Works2
- Installation: Fixing screws/track clips
- 3 communication ports: One RS232 port (DB9 serial port uses FX3U protocol 38400,7,E,1), one RS485 communication port (communication protocol can be set to D8120) and one RS485 communication port (optional) (communication protocol can be set to D8120)
- Analog inputs: 6CH analog input and 12-bit accuracy (default 3CH voltage: 0-10V and 3CH current: 0-20MA). Can be changed to full voltage or full current according to customer needs. Read analog quantity with RD3A instructions
- Analog output: 2CH analog output, 12-bit accuracy and output voltage 0-10V. The output analog voltage is commanded with WR3A
- Temperature module: Supported. The analog quantity can be modified to NTC, two options are available: 1. NTC10K (-40℃ to 150℃); 2. NTC50K (-40℃ to 210℃). There is an additional charge for changing the number of NTC channels, and a maximum of 6 NTC channels can be changed
- Input point X element: X0-X17, DC24V input and low-level active. X0-X5 are high-speed counting input ports (12KHZ). 60KHz is available for an additional fee
- Output point Y element: Y0-Y17 are relay output, and the relay output current is 5A (except for the pulse port). 1 common port for 8 relays, and there are 2 common ports in total

Applications:
- For automation equipment, including lifting machinery, elevators, lifts, mask machines, food delivery machines, cutting machines, printing machines.

Package Included:
- 1 x PLC Controller

Note:
- Please note that the transfer speed of the FX3U is set to 38.4K.

Packaging Details:
- G.W.: 0.4kg

FAQ:
1. What should I do if the PLC cannot be connected to my computer?
A: FX1N and FX3U series PLCs have keyword protection function, which can only be read and written after opening the ladder diagram project. Please check the following two points: 1). Whether the ladder diagram project is open or a new project is created. 2) Whether the COM port is set correctly and whether the baud rate is set correctly (the transmission speed of the FX1N PLC is set to 9.6K; the transmission speed of the FX3U PLC is set to 38.4K).

2. Can it be connected to AC or DC 220V?
A: No. DC24V power supply must be used, otherwise it will burn out the PLC and cause it to fail to work normally.

3. Can it be connected to a touch screen?
A: Most of the touch screens sold in the market can be connected with the PLC, as long as you wiring it correctly.

4. Is it easy to decrypt the programs inside?
A: The PLC has special encryption functions, please check Settings - Parameter Settings - Keywords to set your own password. After the password is set successfully, there is no upload function on the PLC.

5. The PLC I am using now has the same appearance as this product. Can I purchase your PLC to replace my PLC?
A: The PLC we sell is only the carrier of the program, you need to write or import your program into our PLC in order to realize the instructions of the equipment operation.

6. I can't write programs, can you write programs for me?
A: We do not write programs for customers. Thank you for your understanding!
