G410 4 Axis Agriculture Drone Frame Unassembled Wheelbase 1513MM Foldable 10KG Load + Pesticide Tank

Availability: In stock, usually dispatched in 1 business day

  • Price:$1,255.92
  • Price in reward points: 12559 Reward Points: 126
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $1,230.80 $1,205.68 $1,168.01 $1,117.77 Contact US
Quantity:

G410 4 Axis Agriculture Drone Frame Unassembled Wheelbase 1513MM Foldable 10KG Load + Pesticide Tank

Features:

- AGRICULTURAL DRONE FRAME: 10L effective capacity, quick release medicine tank, IP65 waterproof, for multiple uses
- INTEGRATED FUSELAGE FRAME: THE fuselage frame is formed in one body, with simple structure and high strength, it has good durability and reliability
- CROSS FOLDING STRUCTURE: The arm is folded in a staggered way, minimize the size after folding, convenient transportation
- QUICK REMOVAL OF TANK: The plug-in tank is adopted, it can replace tank quickly
- DUSTPROOF AND WATERPROOF: The whole machine is dustproof and waterproof, and the waterproof grade reaches IP65, it can be washed directly with water
- Quadrotor and hexarotor shared frame

G410 Product Parameters:

- Wheelbase: 1513mm
- Unfolded size: 946*1545*673MM
- Folding size: 850*505*673MM
- Tank capacity: 11L
- Frame weight: 6.35kg
- Takeoff weight: 27kg
- Recommended Motor: X8+30inch propeller

Accessories Installation Reference (not included):
- EXTENDED Y-TYPE NOZZLE
- OBSTACLE AVOIDANCE/HEIGHT FIXING RADAR
- BRUSH PUMP
- FPV CAMERA
- RTK POSITIONING
- LAMINATED FC
- Power: Hobbywing X8, 40mm pipe diameter
- Flight control: For Jiyi K++
- Remote control: For Skydroid H12 + camera, for Siyi AK28 + camera
- Battery: For Ace 12S 16000mAh battery

Package Included:
- 1 x Set of frame body (G410)
- 2 x Tripod crossbar assemblies (Diameter 20* Diameter 18*600)
- 2 x Radar mounting poles (Diameter 20*340)
- 4 x Tripod diagonal brace components (Diameter 20* Diameter 18*350)
- 1 x Bag of frame accessories
- 1 x Quick release medicine tank

Note:
- It does not include power system (motor, ESC, propeller, flight control, battery, remote control, etc.), nor water pumps, water pipes, nozzles, etc.
- Assembling is needed.
