GCDQCN 4P 100A ATS Automatic Transfer Switch (4P100A) for 35mm Rail and Lighting Distribution Box
Features:
- Millisecond-level rapid switching: The switching time is less than or equal to 30ms, and the power can be uninterrupted during switching.
- Small size: Its appearance is completely upgraded. Its overall length is shorter than that of a mobile phone.
- One-piece design: It saves installation space due to small size, with light weight.
- Industrial silver contacts: The contacts greatly improves the service life and conductivity of the ATS switch.
- Manual and automatic modes: The switch supports manual and automatic modes. The interlocking mechanism of air switch style is used to make it more durable.
- Rail mounting: It can be mounted on a 35mm standard rail and can be easily used with an air switch for installation in a lighting distribution box used in the family.
Specifications:
- Frame current: 125A
- Rated current: 100A
- Number of poles: 4P
- Short circuit breaking capacity: 6kA
- Product grade: PC class
- Rated voltage: 400V
- Wiring: two in and one out
- Installation: Supports 35mm rail
- Electrical life: 10000
- Mechanical life: 10000 times
- CCC rated voltage range: above 50V and below 440V
Package Included:
- 1 x ATS switch
Packaging Details:
- Weight: 0.8kg
