GPS+ Beidou Four Frequency Spiral Antenna Omni-directional Rubber Stick UAV BT-560 Antenna
Description:
BT-560 antenna is the four arm spiral structure. It can receive the signal from frequency GPS L1/L2 and BDSB1/B2 and GLONASS G1/G2. It can be used in double system, high precision surving and mapping and malitiary location. Also can be used in UAV, land surving, road construction, ocean surving, terminal container operation, combat exercises, border guards, etc.
Feature:
- High temperature resistance, waterproof, anti UV
Parameter:
- Operating frequency: L2/B2/G2, L1/B1/G1
- Vertex gain: >=2.5dBi, >=3dBi
- Polarization mode: RHCP
- Output Impedance: 50 ohm
- Output SWR: <=1.5
- Gain: 35+-2db
- Noise index: <-2db
- Operating current: <=25mA
- Operating voltage: 3-5V
- Interface: SMA
- Size: 31mm x 56mm
- Weight: 19g
- Operating temperature: -40~80degree ceisius
- Storge temperature: -55~85 degree ceisius
- Humidity: 45%-95%
Package included:
- 1 x BT-560 Antenna
