GY-521 MPU-6050 Module 3 Axis Accelerometer Gyroscope 6DOF Module for Arduino

GY-521 MPU-6050 Module 3 Axis Accelerometer Gyroscope 6DOF Module for Arduino

Description:
MPU-6000 is first one that integrated 6 axis motion processing components, compared to the multi component program, the problem of the differential between the combination of gyroscope and accelerator is solved. Mpu-6000 integrates 3-axis gyroscope, 3-axis accelerator, and contained by the second I2C port connecting other accelerator, magnetic sensor, or other sensor digital motion processing (DMP: digital motion processor, hardware acceleration engine, by the main I2C port to a single data stream, output the end of the application complete shaft 9 fusion calculus technique

InvenSense's motion processing database, which can deal with the complex data of motion sensing, reduces the load of the operating system, and provides the architecture of API.

Mpu-6000 angular velocity of the complete lattice sense measurement range is + 250, 500, 1000 + and + 2000 DEG / sec (DPS), accurate tracking Zong fast and slow motion, and, users can program control of accelerator complete lattice sense measurement range is 2 G +, + 4G + 8g and + 16g. Product transmission can be transmitted through the highest to I2C 400kHz or up to SPI 20MHz.

MPU-6000 can work under different voltage, the voltage of VDD is 2.5V + 5%, 3.0V + 5%, 3.3V + 5%, VVDIO + 5% is 1.8V +. MPU-6000's package size 4x4x0.9mm (QFN). Other features include the built-in temperature sensor, including oscillator.

Specification:
- Chip: MPU-6050
- Power supply :3-5v (internal low dropout regulator)
- Communication modes: standard IIC communications protocol
- Chip built-in 16bit AD converter, 16-bit data output
- Gyroscope range: ± 250 500 1000 2000 ° / s
- Acceleration range: ± 2 ± 4 ± 8 ± 16g
- Immersion Gold PCB machine welding process to ensure quality
- Pin pitch 2.54mm

Application:
- Motion sensing game
- Augmented reality
- Electronic image stabilization (Electronic Image Stabilization EIS:)
- Optical image stabilization (Optical Image Stabilization OIS:)
- Pedestrian navigator
- "Zero touch" gesture user interface
- Posture shortcuts
- Authentication

Market:
- Intelligent mobile phone
- Tablet device
- Handheld game products
- 3D remote control
- Portable navigation device

Features:
- The Fusion data of 6-axis or 9-axis Rotation matrix with digital output, quaternion),Euler Angle forma
- 131 LSBs/°/sec sensivity and the 3-axis gyroscope sensing range ±250、±500、±1000与±2000°/sec
- Programmable control, and the program control range is + 2G + 4G + 8g + 16g 3 axis accelerator.
- Remove accelerator and gyroscope axis sensitivity, reduce the influence of setting  and sensor drift.
- Digital Motion Processing (DMP:) engine can reduce the complexity of the data of the fusion algorithm, sensor synchronization, posture induction, etc..
- Motion processing database supports Linux, Android and Windows
- The operation time deviation and the magnetic sensor calibration algorithm are exempted from the requirement of the customer.
- Temperature sensor with digital output
- Digital input pin (pin Sync) to support video and electronic image stabilization technology and GPS
- Can control program interrupt (interrupt) support posture recognition, pan, picture zoom, rolling, rapid decline of interruption, high-G interrupt, zero action induction, bunt induction, shaking sensing function.
- VDD supply voltage: 2.5V + 5%, 3.0V + 5%, 3.3V + 5%, VDDIO + 5%
- Gyro operation current: 5mA, standby current: 5 μA; accelerator operation current: 350μA, accelerator power saving mode current: 20μA@10Hz
- I2C, 400kHz; 20MHz, SPI serial host interface
- User test
- 10000 g collision tolerance
- RoHS and environmental standards

Package included:
- 1 x GY-521 MPU-6050 Module
