Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
---|---|---|---|---|---|
Price /Unit | $72.86 | $71.38 | $69.15 | $66.17 | Contact US |
HD-4800C 48MP FHD Camera V8 Industrial Camera CCD Camera (Blue) with HDMI-Compatible & USB Outputs
Features:
- 48MP industrial camera
- With HDMI-compatible and USB output interfaces
- A TF card can be used to take photos, make videos and for playback
- It can be connected to a PC via USB port for measurement
Specifications:
- Model: HD-4800C
- Image sensor: 48MP CMOS sensor for Panasonic
- Sensitive size: 1/2.3". It has a larger field of view than the usual 1/3 inch
- Pixel size: 1.335μm x 1.335μm
- Output interface: HDMI-compatible (type A), USB (type B) and TF Card
- Photo resolution: 48MP
- Video resolution: 2K at 30 fps and 1080p at 60 fps
- HDMI-compatible output: progressive 1920*1080 60 frames. HDMI-compatible output and USB output are supported at the same time
- HDMI-compatible output ratio: Supports 4:3, 16:9 and 16:10 screens, to ensure that the image is not distorted
- USB2.0 output (no driver): 1920*1080 at 30, 1280*720 at 30 and 640*480 at 30. USB output and HDMI-compatible output are supported at the same time
- TF card capacity: up to 64GB
- White balance: One-key white balance/automatic/manual, and R, G and B can be adjusted individually
- Exposure: Manual/Automatic. The exposure value is adjustable
- Reticle: 8 strips, and adjustable color, thickness and position
- Cross markings: 2 with graduations
- Crosshair: 2 strips, and color, thickness and position are adjustable
- Sharpness, contrast & saturation: Supported and adjustable
- Black & white, negative: Supported
- Mirroring: Horizontal and vertical mirroring
- Language: Chinese/English
- Digital zoom: Supported
- Remote control: Supported. Take photos and videos remotely, and the picture does not shake
- Input voltage: DC12V (support 5-19V), 55-21 large interface
- Power consumption: 0.15W maximum (12V, 0.12A)
- Lens mount: C/CS mount
- Net weight: 180g
- Product size: 64mm*64mm*35mm
Package Included:
- 1 x Camera
- 1 x Power adapter
- 1 x Remote control
- 1 x Type B square USB cable
- 1 x Instructions
Packaging Details:
- G.W.: 0.45kg
- Packaging size: 160mm*100mm*80mm
Note:
- TF card is not included in the package.
