Hi-End Golden Power Amplifier HiFi Stereo 2.0 Channel Post-Amp 2x150W

Hi-End Golden Power Amplifier HiFi Stereo 2.0 Channel Post-Amp 2x150W


Product Description:
- Classic Power Amplifier (The Hi-End Golden Version)
- The FM 300A is Swiss FM ACOUSTICS a classic amplifier,but its price is very high.In order to let you can hear the legend voice, with a kind of reverence after about a year of fighting, this clone machine was able to completed. 100% according to the original machine to make, the whole structure is exactly the same, exactly the same circuit traces, exactly the same protection circuit, as much as possible to ensure that the same components (the triode are all used in second-hand disassemble transistor, carefully selecting and pairing ), has been seeking for infinite close to the original machine appearance and sound.

Components selection:
- Dual power transformers are powered separately
- Custom-made Nippon Steel(NSSC) iron-core copper-wire 400W toroidal transformer
- Custom-made high-current short-key way with LED Power Switch
- R0E genuine 63V4700UF filter capacitor (only 108PCS in stock now, after sell we will change the capacitor to other model)
- Panasonic 20K single-linkage volume potentiometer
- Amplification part the small resistance use UK WEL
- Power resistor use Philips or DALE
- Triode and transistor are use second-hand disassemble products.

Parameters:
- Output Power: 80W X2 @8Ω——150 watt X2 @4Ω
- Frequency Response: 20Hz ~ 20kHz 3Hz ~ 150kHz (1W output)
- Total harmonic distortion: 0.02% (20Hz ~ 20kHz)
- Impedance: 4-16 Ω
- Power: 110V(115V) / 220V(235V)
- Chassis size:  width 430 × height 88 × deep 268 mm
- Weight: 11.2KG (About 13kg with package)

Package List:
- 1 x  2x150W Power Amplifier
