High Performance Brushless T-Motor MT2826 380KV/550KV/760KV for Quadcopter/Multi-Rotor
Features:
- All of our motors come with extremely permanently lubricated EZO ball bearings from Japan.
- All the stators of our motor are made with NO.1200#0.2mm sukucib laminations from Japan for maximum efficiency and minimum eddy current losse. High quality stator plates are epoxy coated on the inner surface to prevent winding shorts
- Specially designed N45uh magnets with a 200 C (392 F) temperature rating for trouble-free operation.
- All motors sound and feel perfect, the bearings sound great, they don’t sound at all.
- Oxygen-free copper wire temperature of 180 degrees is used in winding the motors.
- CNC Machined aluminum front and rear housing with cooling holes that pump air through the motor while it runs.
- Orderly winding configuration
- Offering perfect balance movement performance.
- Rear threaded mounting holes with both hole spacing fit a variety of applications.
- A machined aluminum cross style mount and a threaded prop mount is included with every motor, along with a wobbly adapter on select models.
- To sum up, creating a high quality T-motor motor
| item number | MT2826 KV760 prop ：14*4.7 carbon prop | |||||
| Volts/V | Throlle | Amps/A | Thurst/g | Power/W | Efficent(G/W) | ℃ full throlle in 10min |
| 14.6 | 50% | 8.3 | 940 | 121.18 | 7.76 | |
| 65% | 13.3 | 1280 | 194.18 | 6.59 | ||
| 75% | 20.2 | 1700 | 294.92 | 5.76 | ||
| 85% | 28.7 | 2120 | 419.02 | 5.06 | ||
| 100% | 36 | 2400 | 525.6 | 4.57 | 60℃ | |
| item number | MT2826 KV760 prop：12*3.8 carbon prop | |||||
| 14.6 | 50% | 6.7 | 750 | 97.82 | 7.67 | |
| 65% | 9.4 | 960 | 137.24 | 7.00 | ||
| 75% | 12.4 | 1150 | 181.04 | 6.35 | ||
| 85% | 17.8 | 1520 | 259.88 | 5.85 | ||
| 100% | 23 | 1780 | 335.8 | 5.30 | 45℃ | |
| item number | MT2826 KV760 prop：APC14*4.7 | |||||
| Volts/V | Throlle | Amps/A | Thurst/g | Power/W | Efficent(G/W) | ℃ full throlle in 10min |
| 14.6 | 50% | 9.4 | 1020 | 137.24 | 7.43 | |
| 65% | 16.7 | 1480 | 21608 | 0.07 | ||
| 75% | 24.1 | 1880 | 351.86 | 5.34 | ||
| 85% | 33 | 2250 | 481.8 | 4.67 | ||
| 100% | 41.4 | 2550 | 604.44 | 4.22 | 70℃ | |
| MT2826 KV760 Prop：APC12*3.8 | ||||||
| 14.6 | 50% | 7.3 | 800 | 106.58 | 7.51 | |
| 65% | 12.1 | 1120 | 176.66 | 6.34 | ||
| 75% | 18.8 | 1530 | 274.48 | 5.57 | ||
| 85% | 27.2 | 1910 | 397.12 | 4.81 | ||
| 100% | 34.4 | 2190 | 502.24 | 4.36 | 52℃ | |
| MT2826 KV760 Prop：14*8 Wooden prop | ||||||
| 14.6 | 50% | 9.1 | 920 | 132.86 | 6.92 | |
| 65% | 15.5 | 1350 | 226.3 | 5.97 | ||
| 75% | 22 | 1700 | 321.2 | 5.29 | ||
| 85% | 32.6 | 2200 | 475.96 | 4.62 | ||
| 100% | 40 | 2400 | 584 | 4.11 | 63℃ | |
