Hobbywing EZRUN MAX10-SCT 1:10 Brushless ESC Waterproof Electronic Speed Controller for Car
Manual : Click here
Specifications
- Product Name: EzRun MAX10 SCT
- Scale: 1/10th
- Brushed/Brushless: BL
- Sensored/Sensorless: SL
- Waterproof: Yes
- Cont./Peak Current: 120A/760A
- Input: 2-4S LiPo/6-12 Cells NiMH
- BEC Output: Switch Mode:6V/7.4V,4A
Wires & Connectors
- Input Wires: Red-12AWG-200mm*1/Black-12AWG-200mm*1
- Output Wires: Black-12AWG-200mm*3
- Input Connectors: No
- Output Connecotors: 4.0 Bullet Connectors (Female)
- (Note: All the wire length above is the original length not the length you see from the outside.)
Fan
- Size: 25.0x25.0x10.0mm
- Voltage Range: 5-7.4V
- Powered by: Powered by BEC
ESC Programing:
- SET Button on ESC: Supported
- LED Program Box: Supported
- LCD Program Box: Supported
- WiFi Module: Supported
- Program Port: FAN/Program Port
Firmware
- Firmware Upgrade: Supported
Size & Weight
- Size: 49.0x39.5x34.7mm
- Weight: 105g
Applications:
- Motors: SL BL Motors/SD BL Motors(only in SL mode)
- Vehicles: 1/10thSCTs/Truck/Monster Truck
- KV Rating/T Count: 2S LiPo:KV≤6000;3S LiPo:KV≤4000;4S LiPo:KV≤3000(36XX Series of Motors)
Package List:
- 1 x Hobbywing EZRUN Brushless ESC
