Hobbywing XERUN XR8 PLUS 150A Brushless ESC Electronic Speed Controller for 1/8 Touring Car Crawler
Specifications
- XERUN XR8 PLUS Brushless ESC Electronic Speed Controller
- Cont./peak Current: 150A/950A
- Motor Type: Sensored / Sensorless Brushless Motor
- Applications: 1/8th Scale On-road, Buggy, Truggy for High-level Races
- Motor Limit:
- 4S LiPo/12S NiMH:KV LiPo/NiMH Cells: 2-6S LiPo, 6-18S NiMH
- BEC Output: 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC)
- Cooling Fan: Powered by the stable BEC voltage of 6V/7.2V
- Connectors: Input End: No, Output End: No
- Size/Weight: 58.7 (L) x 48 (W) x 36.9 (H)/ 127g (W/O Wires)
- Programming Port: FAN/PRG Port
Features:
- Compatible with sensored/sensorless brushless motors. In sensored mode, it’s compatible with most popular sensored brushless motors on the market. In sensorless mode, it’s compatible with 99% of brushless motors on the market.
- Super internal switch-mode BEC with switchable voltage of 6V/7.4V and cont. /peak current of 6A/15A for easily driving big torque servos and high voltage servos.
- Highly reliable electronic switch avoids troubles which may happen to traditional mechanical switch due to dirt, water, dash and etc.
- Aluminum cases build highly efficient heat dissipation system.
- Separate programming port to easily connect the LCD program box to the ESC.
- Proportional brake with 9 levels of Maximum Brake Force and adjustable Drag Brake Force range from 0 to 100%.
- 9 levels of acceleration/punch from “soft” to “aggressive” for different vehicles, tires and tracks.
- Innovative “COAST” function will make the RC vehicle coast like a real car after you release the throttle trigger, avoid the sudden slow-down (this sudden slow-down often happens to motors with very strong magnetic force), and brings you the great control feel.
- Multiple protections: motor lock-up protection, low-voltage cutoff protection, thermal protection, overload protection, and fail safe (throttle signal loss protection).
- Advanced programming via the portable multifunction LCD program box.
- Firmware upgrade via HOBBYWING multifunction LCD program box (item sold separately).
Package List:
- 1 x HOBBYWING XERUN Brushless ESC Electronic Speed Controller
