HTRC T150 150W RC Balance Charger Touch Screen for LiPo NiMH Battery Discharger

HTRC T150 150W RC Balance Charger Touch Screen for LiPo NiMH Battery Discharger

Description:
T150 is a new design multi-functional high power balance charger by HTRC,Utilizing 3.2 inch color LCD Toch screen display,easy operation, built-in cooling fan,DC 11-18V or AC 100-240V dual power.Max charger power 150w,Max charge current 10A.Designed for charging LiPo LiFe Lilon LiHV NiCd NiMh Pb Smart Batteries.

Besides it has a 5V 2.1A USB DC output port, which can be a power supply to other electronic products.

Features:
*Compact touch screen charger, easy to carry, easy to use.
*Practical for variety of batteries.
*Automatic identification of Li-Po batteries cells counts
*Built in cool fan for easy heat dissipation
*Graph display of charging status
*Multiple charging modes.
-Lipo/Lilo/LiFe/LiHv: balance charge, charge, storage, discharge.
-NiMH/NiCd: Charge, Discharge, Cycle.
-PB: Charge,Discharge,Trickle.
*Multi-function:
-Battery Meter:Display lithium battery cell counts,battery capacity percentage,each cell's  voltage. (does not support 1s battery)
-TVC(Terminal voltage control):The Charger allows user to set the charge/discharge end voltage.
-Lithium Battery internal Resistance Check: can display each cell's resistance.(does not support 1s battery)
-Calibration: cell voltage monitoring and calibration. (caliration function for 6s battery only)
-Smart battery:Smart battery I,II,III,and Digital DC Power.(Need optional DJI Charging cable)
*5V 2.1A USB port.
*Data storage and loading
*Battery break in and cycling.
*Maximum Safety:Automatic charge current limit,Delta-peak sensitivity, capacity limit, processing time limit,temperature threshold.
*Built-In PFC
*Firmware update.

Specifications:
- Input: AC 100-240V / DC 11-18V
- Charge power:Max 150W
- Discharge power: 10W
- Charge current range: 0.1-10A
- Discharge current range: 0.1-2A
- Lilon/LiPo/LiFe/LiHV cell count: 1-6cells
- NiCd/NiMH battery cell count: 1-15cells
- PB Battery voltage: 2-20V
- Smart battery: I/II/III
- Current drain for balancing: 500mA/cell
- Net Weight: 0.48kg
- Dimension: 145*105*64mm

Package Included:
- 1 x T150 Charger
- 1 x Charge Cable Banana Plug to T-Plug
- 1 x Extension Charge Cable T-Plug to XT60
- 1 x Balance Board with Pin Cord
- 1 x AC Cord (US EU UK AU optional)
- 1 x DC Cord
- 1 x User's Manual
