Product Description:
- Mono to balance mode input.When the power increases,it can drive large power loudspeaker amplifier.
- Outline size:162x62x261(WxHxD)
- Inner size:155x54x250(WxHxD)
- Silver white lines drawing front panel,black lines drawing back panel.
- Output power:450W
- Not support APP
- Impedance:4ohm
- Weight:0.5kg
Specification:
- ICEpower125ASX2
- Rated power:1% THD+N,SE mode,4Ω,1kHz2 x 125W rated power:1%,THD+N
- BTL mode,4Ω,1kHz450W the max power:10%,THD+N
- BTL mode,4Ω,1kHz550W rated power:1%,THD+N
- SE mode,8Ω,1kHz2 x 65W rated power:1%,THD+N
- BTL mode,8Ω,1kHz250W,the max power:10%,THD+N
- BTL mode,8Ω,1kHz300W bandwidthL8Ω,-3dB point
- SE mode120kHz frequency respond,20Hz-20kHz,2Ω-8Ωload range+/-0.5dB,Damping factor:8Ω,100Hz>500
- Total harmonic distortion:THD+N 1kHz,1W0.003% dynamic range SNR,SE mode117dB dynamic range SNR,BTL mode121dB
- Dimension:16x8x3.5cm
Package List:
- 1 x ICEPOWER ICE125ASX2 Digital Amplifier Module
