| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $1,337.24 | $1,309.95 | $1,269.01 | $1,214.43 | Contact US |
Features:
- Hand-made construction with the finest point-to-point wiring.
- Specially designed EI transformer for power supply.
- Two EI output transformers with wide bandwidth are applied.
- Two 12AX7s and 12BH7s are used in the preamp stage.
- Four KT88 tubes are used for AB1 push-pull amplification.
- Provide the triode and super linear selection function. Triode, voice soft, pure and
smooth, suitable for appreciation vocals, string and other types of music; Super linear
works, Yang loud, bold and unrestrained, imposing manner is good, suitable for enjoy big
scenes, such as large dynamic types of music.
- Triode and Ultra linear selection.
- Soft Start and time-delay circuit. (30 seconds)
- ALPS volume control and Realcap capacitors are applied.
- Remote control for all functions.
- User bias control is accessible on top of the amplifiers panel with true ampere meter.
-- Convenient installation drawing plug-in valve cap
Specification:
－Power output: 22W+22W(RMS Triode operation)
32W+32W(RMS Ultra linear operation)
－Frequency response：10Hz~50kHz(-1.5dB)
－THD:1%（1kHz）
－S/N Ratio: 87dB
－Input Sensitivity: 220mV
－Input Impedance: 100kΩ
－Output Impedance: 4Ω ,8Ω
－Dimension (WxDxH): 373mm x345mm x191.5mm
－Tube Complement: 12AX7x2 12BH7x2 KT88x4
－Net weight: 19.6kg
－Power Consumption: 240W
Silver
