| Quantity | 3+ units | 10+ units | 30+ units | 50+ units | More |
|---|---|---|---|---|---|
| Price /Unit | $969.22 | $949.44 | $919.77 | $880.21 | Contact US |
Product features:
- Hand-made construction with the finest point-to-point wiring.
- Specially designed EI transformer for power supply.
- Two EI output transformers with wide bandwidth are applied.
- Two 12AX7s and 12AU7s are used in the preamp stage.
- Four EL34 tubes are used for AB1 push-pull amplification.
- Triode and Ultralinear selection.
- SoftStart and time-delay circuit. (30 seconds)
- ALPS volume control and Realcap capacitors are applied.
- Remote control for all functions.
- User bias control is accessible on top of the amplifiers panel with true ampere meter.
Specification:
－Power output：15W+15W（RMS Triode operation）
32W+32W（RMS Ultralinear operation）
－THD：1%（1kHz）
－Frequency response：10Hz～50kHz（-1.5dB）
－S/N Ratio：88dB
－Input Impedance：100kΩ
－Output impedance: 4 Ω, 8 Ω
－Input Sensitivity：200mV
－Tube Complement：12AX7×2、12AU7×2、EL34×4
－Dimension (WxDxH)：376mm x 345mm x 191.5mm
－Net weight: 19.6kg
－Power Consumption: 230w
－Working conditions: temperature: 0 ℃ to 40 ℃ Moisture: 20% ~ 80%
－Storage conditions: temperature: - 20 ℃ ~ 70 ℃ Moisture: 20% ~ 90%
