LS-20 14-54MHz 200W High Quality Telescopic Shortwave Antenna with Base High Position Fishing Rod Antenna

LS-20 14-54MHz 200W High Quality Telescopic Shortwave Antenna with Base High Position Fishing Rod Antenna

Features:
- Optimized Signal Reception: LS-20 shortwave antenna is a high-level artifact designed to enhance your radio communication experience. With its antenna manual and RV antenna notes picking up channel capabilities, this antenna is a must-have for ham radio base station antennas. The antenna's design is not only aesthetically pleasing but also engineered to provide superior signal reception. The 5-meter 6 pull rod ensures that you can extend the antenna to the optimal height for optimal signal pickup, making it an excellent choice for those who demand the best in radio communication.

- Versatile Installation Options: LS-20 shortwave antenna is not just about performance; it's also about versatility. Whether you're looking to install it on your balcony, window, or base, this antenna is designed to fit seamlessly into your environment. The included kettle frame, ground grid, and black fixed rod make installation a breeze, allowing you to set up your antenna quickly and efficiently. The antenna's lightweight and portable design make it an excellent choice for those who are always on the move or have limited space.

- Built for Durability and Performance: crafted from high-quality stainless steel and durable plastic, the LS-20 shortwave antenna is built to withstand the elements. The antenna's robust construction ensures that it can withstand the rigors of outdoor use, making it an ideal choice for those who enjoy outdoor radio communication. The antenna's performance is further enhanced by its manual leadzm antenna design, which allows for precise adjustments to optimize signal reception. Whether you're a seasoned radio operator or a beginner, LS-20 shortwave antenna is the perfect addition to your radio communication setup.

Specification:
- Frequency: 14 - 54MHz
- Power: 200W
- Thread specification: M10 for telescopic rod; 3/8 inch and 1/4 inch for fixing rod, which can be connected to general photographic tripod.
- Weight:
  Base (including ground grid, kettle bracket, fixing rod, etc): 630g
  Telescopic rod: 260g
- Corrugated coil: use a feeder near the antenna, with a diameter of 15cm, 7-8 turns, unbalanced antenna, and must be wound.

Installation:
- The installation method is very simple. Twist the fixed rod onto the photography tripod or lamp stand (not included), place the counterweight in the kettle stand, try to get as close to the window as possible, level the ground grid, and pull out the rod section by section. The rod should not touch other objects and should be kept as far away from metal as possible. Based on the quarter wavelength of the frequency used, use a talent or standing wave meter to observe and adjust the length of the rod to minimize SWR (generally, the rod should be shorter than 1/4 wavelength). After debugging, it can be used. The theoretical frequency range of the antenna is 14MHz-54MHz, and the lowest point of the standing wave can be adjusted to 1.2. However, the actual situation of each frequency point will vary with the surrounding objects of the window (such as steel bars in the wall, anti-theft nets, etc.). The antenna can be adjusted to expand the frequency range. It is recommended to prepare a set of antenna analyzer for use, and at least a power standing wave meter is needed.

Package Included:
- 1 x Antenna
- 1 x Base
