Mastech Digital Multimeter MS8250A Multimetro Capacitance Frequency Meter VS Fluke F17B 15B
Description:
- MS8250A digital multimeter is a portable and professional measuring device with LCD display and backlight, it is easy to read by users. This multimeter measuring range switch operated with one hand for convenience. This multimeter has overload protection and low battery indicator. It is the perfect multifunctional Meter for professionals regardless of factories, schools, fans or family use.
- Comply IEC61010-1 600V IV standard
- LCD Display 3999 counts
- Full range overload
- Auto / manual range options
- measure AC voltage, DC voltage, AC current, DC current, frequency, duty ratio, resistance, capacitance.
- Maximum, minimum / relative value measurement
- Diode/ Continuity test
- Automatic shutdown / Data Hold
- Background light function
- Non-contact voltage detection
Equipment parameters:
DC voltage: 400mV / 4V / 40V / 400V / 1000V ± (0.5% + 2)
AC Voltage: 400mV / 4V / 40V / 400V / 750V ± (0.8% + 2)
DC Current: 400uA / 4mA / 40mA / 400mA ± (0.8% + 2), 4A / 20A ± (1.2% + 2)
AC current: 400uA / 4mA / 40mA / 400mA ± (1.5% + 2), 4A / 20A ± (3% + 2)
Resistance: 400Ω / 4kΩ / 40kΩ / 400kΩ / 4MΩ / 40MΩ ± (1.2% + 2)
Capacitance: 50nF / 500nF / 5μF / 50μF / 100μF ± (3% + 5)
Frequency: 50Hz / 5kHz / 50kHz / 500kHz / 5MHz ± (0.5% + 2)
Duty Cycle: 0.1% ~ 99.9% ± (2% + 2)
Power: 9v 6F22
Weight: 250g
Size: 180mm x 86mm x 52m
Package list:
- 1* MS8250A multimeter
- 1* test leads
- 1* manual
not include the battery
