Maxgeek DSE710 Diesel Generator Controller Genset Auto Start Control Module Controller Panel LCD Display

Maxgeek DSE710 Diesel Generator Controller Genset Auto Start Control Module Controller Panel LCD Display

Description:
The DSE710 is an Automatic Start Control Module that offers an advanced range of engine monitoring and protection features. The module has been designed to monitor generator frequency, generator volts, generator current, engine oil pressure, engine coolant temperature, engine running hours and battery volts. The module also displays the engine speed. When the module detects a fault condition it automatically shuts down the engine and indicates the exact fault on the modules LCD display or relevant LED indicator. The module can be configured using the front panel or via the DSE810 interface and a PC. The module can also be controlled from a PC that is located up to 100 meters away.

Feature:
- PC/Front panel configuration
- Digital and analogue inputs
- Digital outputs
- Automatic shutdown or warning when fault conditions are detected
- Automatic/Manual/Remote start
- Engine pre-heat
- Engine monitoring and protection features
- Protected Solid State (PSS) outputs

Specification:
Power Supply: 8 to 35V DC continuous
Cranking Dropouts: able to survive 0 V for 50mS, providing supply was at least 10 V
before dropout and supply recovers to 5V. This is achieved without the need for internal batteries.
Max Current: operating: 180mA at 12V, 190mA at 24V; standby: 145mA at 12V. 150mA at 24V
Alternator Input Range: 35V(L-N) to 277V(L-N) AC (+20%) 50Hz - 60Hz (min 15V AC)
Auxiliary Output: solid state 2.4A DC at supply voltage
Fuel/Start Output: solid state 3.4A DC at supply voltage
Generator C.T. : 5A secondary 0.5VA
Operating Temperature Range: -30 to +70℃

Package List:
1 x Generator Controller
