Maxgeek MGC120 Genset Controller Generator AMF Control Panel ATS Controller Module Auto Start/Stop
Description:
The MGC120 petrol generator set controller is an AMF module that can be used in the automation and monitoring system of a single gasoline generator set. Through data measurement, the functions of automatic start/stop, alarm protection, ATS switching control of the generator set are realized. The controller adopts LED digital tube display and touches the button operation. Most of the parameters can be adjusted from the front panel of the controller. Through the LINK interface, all parameters can be adjusted from the PC. MGC120 gasoline generator set controller has the advantages of simple operation, reliable operation, compact structure and convenient installation. It can be widely used in the automation system of various gasoline generator sets.
Package List:
1 x Genset Controller
Note:
-S11, S12, S21, S22 are separately connected with orange wire, pink wire, yellow wire, and blue wire, and stepper motor COM (red wire) shall be connected with the battery positive.
-Terminal 11 must be connected in series with diode. Diode capacity shall be over 1A, and reverse pressure-standing value shall be over 1000V.
-The maximum incoming current for programmable output 1 and output 2 shall be 1A.
