Mechanical Arm 7 Axis Robot Arm 7DOF Robot Arm HM-MS10 Servo For DIY Education Robot Competition

Mechanical Arm 7 Axis Robot Arm 7DOF Robot Arm HM-MS10 Servo For DIY Education Robot Competition

Features:
- Stable to Use: the base is fixed with high quality steel bearings
- Higher Torque: this 7 Axis robot arm comes with HM-MS10 Servo
- High Quality: the whole structure is built with thickened aluminum alloy
- Highly Precise: 7 DOF is for active joint bearing connection and high precision
- Widely Used: it can also be used in teaching and robot researches

Specifications:
- Name: 7 DOF Robot Arm
- Type: DIY Robot
- Suggested Clamping Load: 400g

MH-MS10 Servos:
Electrical Parameters:
- No-load Speed: 0.16sec/60°@6V, 0.14sec/60°@7.2V
- No-load Current: 80MA @6V, 100MA @7.2V
- Stall Torque: 15kg*cm @6V, 20kg*cm @7.2V
- Stall Current: 4MA @6V, 5MA @7.2V

Mechanical Parameters:
- Structural Max. Angle: 180°
- Weight: 60g
- Lead Specification: 28#PVC
- Lead Length: 320mm
- Servo Type: Cross, disc, hexagon, strip types
- Gear Material: Metal Gear

Control Parameters:
- Working Voltage: 5-7.4V
- Working Frequency: 50-330Hz
- Operating Angle: 180° (500 to 2500μ sec)
- Pulse Signal Imaginary Position: 3μ se
- Rotation Direction: Counterclockwise (500 to 2000μ sec)
- Pulse Width Range: 500 to 2500μ sec
- Movable Angle Range: 180°
- Operating System: Change the width of the pulse

Package Included:
- 1 x 7-Axis Robot Arm
- 7 x HM-MS10 Servo Servos

Note:
- Please note that there is no any controller or battery included in this package.
- For shipping convenience, this product is unassembled. Self assembly is needed. Thank you!
